The agricultural perception system has been fully upgraded. The new ALS spot array scanning laser compound eye and active directional control array radar have more comprehensive obstacle avoidance capabilities, with a 360 degree x 180 degree ultra wide viewing angle for full area obstacle avoidance. The observation distance has been increased to 150 meters, achieving full coverage of dead tree branches, diagonal lines, and power poles from top to bottom in the work site.
New sport mode has been added, allowing the drone to climb faster and significantly improve lifting efficiency. With a drop of 100 meters, it can transport 5 boxes of 50kg citrus fruits with one battery, resulting in a 25% increase in efficiency. Automatic guidance design, one click search for takeoff and transportation points, reducing manual burden and lowering transportation costs. Cooperate with the new obstacle avoidance system to achieve automatic hovering of obstacles in 360 degrees, avoiding hand flying collisions.
Quickly replace the 80kg broadcasting box with a rotating material cut-off sensor for more accurate material cut-off judgment. Equipped with a replaceable blade mixer, the material can be rapidly sown at a speed of 280 kg/min. The material movement trajectory is intelligently calculated, and the broadcasting amplitude is accurately set with an error control of less than 10 cm, significantly reducing replay missed broadcasting.
Technical parameter advantages:
1. Maximum wheelbase: 2600mm
2. External dimensions: 1324 * 800 * 950mm (folded)
3. Standard capacity of medicine box: 70L
4. Number of standard nozzles: 4
5. Maximum effective spray width: 15 meters
6. Rated load capacity of spreader: 80KG
7. Battery capacity: 45000mAh
8. Maximum flow rate: 4 nozzles: 40L/min
9. Atomized particle size: 10-300um
10. Lifting load capacity: 75KG
11. Working/Charging Time: 12min/9min
12. Protection level: Module IP67, whole machine IPX6K
13. Charging power: 13000W
