Specification


LIGHT SOURCE

Lamp: 37pcs*15W  RGBW 4 in 1 LED

Lifespan: 50,000H



OPTICS

Beam angle: zoom 4°~60°



COLORS

RGBW linear color mixing



MOVEMENT
Pan movement: 540° optional (16 bit )

Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth



FEATURES

Dimmer: 0-100% linear electronic dimmer

Strobe: 1-25Hz or random

Color change controlled in independent groups, create chasing effect

Built-in macros function

Electronic dimming, color strobe effect

General dimming and blackout for all colors

Perfect pulse and rainbow effect

Smooth RGBW color mixing



DISPLAY

2.4 inch full color LCD screen, show customer logo

15 second standby auto lock



SOFTWARE

Control mode: DMX512, master-slave, auto-run, sound activate

Channel: 18CH/24CH



OTHER SPEC

Fixture and lamp usage time display

Highly positioning precision

Built-in analyzer for easy fault finding, error messages

Input signal isolating protection

fan cooling and temperature auto detection

Housing: high temperature UV resistant ABS



POWER
Voltage: AC100-240V, 50/60Hz

Power Consumption: 620@220V

DIMENSIONS AND WEIGHT
Fixture dimension: 42x30x48cm

Packing dimension:

                          50x33x56cm(Carton)

                          70x50x60cm(2 in 1 flightcase)

Net Weight:          18kg

Gross Weight:

                          20kg(Carton)

                          65kg(2 in 1 flightcase)
