400 Tons Melamine Crockery Compression Maker

  • PLC control with well known brand machine parts

  • Durable and stable, quality guaranteed



  • Support ServiceLife-time Service
  • Trainning ServiceYes
  • Machine Weight8000KGS
  • Machine Dimension2.5*1.48*2.85 M

PLC Control Melamine Crockery Compression Machine


 Advantages of Shunhao Machines & Moulds

1. Shunhao Machines & Moulds has been devoted to mechanical production for 18 years, from product development to production and processing, every detail is striving for perfection and pursuit of perfection

2. Shunhao Machines & Moulds has a professional R&D and production team, which is committed to continuously improving the excellent quality of products to ensure a high degree of technical research and development and quality and output.

3. The machine is PLC control and adopts imported Mitsubishi Electric, touch screen adopts Fuji Electric of Japan which is durable and stable, and the quality is guaranteed

4. The melamine forming machine produced by Shunhao and the toilet lid forming machine have high grinding precision, smooth finished surface, high gloss, beautiful and durable

5. Shunhao products cover: melamine molding equipment, toilet lid molding equipment, melamine polishing equipment etc. Complete products and guaranteed quality.

6. Can customize product functions according to customer requirements, pioneering one operator two machines type.


400T tableware moulding machine


How to operate and maintain the melamine molding machine correctly and safely?

1. It is forbidden to assist operation by hand when the machine is running.

2. Remember the position of the emergency stop switch.

3. Workers should wear short-sleeved clothes.

4. Turn off the power of the machine before checking the machine.

5. Trouble shooting should be carried out by experts or technicians.

6. Keep the machine and surrounding environment clean.



Shunhao melamine molding Machines


Technical Parameters

1

Maximum Working Pressure

210kg/cm2

2

Main Cylinder Piston Diameter

Ø500mm

3

Main Cylinder Working Stroke

550mm

4

Adjustable Table Distance

500~960mm

5

Heating Plate Size

900*860mm

6

Working Layers

1 layer

7

Heating Plate Material

45#

8

Tension Column (Heat Treatment Grinding)

Ø125*2350mm

9

Oil Hydraulic Pump

21Mpa

10

Motor Specifications

15HP

11

Heating Sheet Total Power

19.6KW

12

Machine Total Power

30.6KW

PS: Specifications subject to change without notice.
