• Small Pick-and-Place Robot Arms
• Linear Guide Rail Systems
• Pneumatic Actuator Components
• Automated Assembly Line Indexing Tables

• Optical Measuring Equipment
• Laboratory Analysis Instruments
• Scanning and Imaging Devices
• Precision Positioning Stages

• Miniature Gearbox Output Shafts
• Small Conveyor Rollers (Light Load)
• Packaging Machine Tensioning Pulleys
• Stepper Motor and Encoder Assemblies

• Office Equipment Paper Feed Rollers
• Exercise Equipment Light Rollers
• Vending Machine Mechanisms
• Commercial Printer Drum Supports

01. Maintenance-Free Sealing

Equipped with double contact rubber seals (2RS) made from NBR (Nitrile Butadiene Rubber), the bearing permanently retains factory-applied lithium-based grease. The light-contact lip seals provide effective protection against fine dust, moisture, and incidental splashing while maintaining low frictional torque .

02. Ultra-Thin Section Design

Manufactured from high-purity chrome steel (GCr15), this bearing features an extremely slim 6 mm width while maintaining a full 45 mm inner diameter. This thin-section configuration allows equipment designers to significantly reduce housing dimensions without sacrificing shaft rotational accuracy .

03. High-Speed Quiet Operation

The precision-ground raceways and carefully selected miniature balls are manufactured to strict vibration standards (Class V). This ensures exceptionally quiet running characteristics and minimal vibration, making the 6709-2RS ideal for noise-sensitive environments like medical laboratories and office equipment .

Interchange Part Numbers

Common manufacturer equivalents include:

• SKF: 6709-2RS
• NSK: 6709VV
• FAG: 6709-2RS
• NTN: 6709LLU
• KOYO: 6709-2RS / 6709-2RSE
• TIMKEN: 6709-2RS
• MRC: 6709-2RS

Design & Configuration

The 6709-2RS comes standard with double rubber seals, making it the preferred choice for "fit and forget" applications in relatively clean environments where maintenance access is difficult. The extra-thin section design (6 mm width) allows for compact equipment design without compromising on rotational stability.

For applications requiring higher operating temperatures or exposure to aggressive chemicals, full ceramic (Zirconia) versions of the 6709 are also available as a specialized alternative . For maximum speed requirements where contaminant exclusion is less critical, a metal-shielded version (6709-ZZ) can be considered.

"Where space is restricted and reliability is non-negotiable, the 6709-2RS delivers precision performance in an ultra-compact form factor, ideal for light industrial drives, automation, and precision instrumentation."
