800W to 6500W Ultrasonic Tab Welder Welding Machine for Pouch Cell Laboratory

TMAX-VS-40A is a CE Certified ultrasonic metal welder with touch-screen controller. It is designed for welding stacked electrode foils/sheets and tabs onto current collectors to prepare Li-ion pouch cells & cylindrical cells.

The 2000w battery welder can weld stacked electrode with 10-35 layers aluminum foil or copper foil with Al tab and Nickel tab.



Note:If you are not quite clear about what welder would be suitable for you,please consult the sales manager with following parameters,they will find a solution for you:

1. Weld material
2. Thickness of the material

3. Layer number of material

Features	Preset welding programs selectable for Al and Cu (Note: Welding power can be readjusted to fit the needs for welding other types of metals such as Au, Fe, Ni, Ag...).
Input Voltage	AC 110V  or 220V +/-10%, 50/60Hz
Max. Power Consumption	2200W→can be customized
Welding Area	4mm(L) x 4mm(W)→can be customized
Welding Head	The welding heads and welding base are included for welding both aluminum & copper current collectors from 2 to 30 layers
Ultrasonic Frequency	40K Hz→can be customized
Product Dimensions	1.     Controller: 360mm(L) x 480mm(W) x 200mm(H) 2.     Welder: 200mm(L) x 460mm(W) x 270mm(H)
Net Weight	70kg
Compliance	CE Certificate
Warranty	One Year limited warranty with lifetime support
Recommendation	For the pouch cell assembly, we also recommend you the following items:                                                     Forming machine             Hot sealer with tab          Vacuuming seal                                       Stacking machine                    Die Cutter          Al Laminated Film
