8011 High Purity Aluminum Foil for Battery Cathode Substrate

High quality battery grade Aluminum Foil Roll for lithium ion battery cathode current collector



High Quality Aluminum Foil for Lithium battery cathode Substrate Material


Aluminum Foil Roll For Lithium Ion Battery Cathode Current Collector

Width:100mm-300mm customized;

Thickness:16um

Exported Grade Aluminum Foil for Lithium Battery Cathode Substrate

Item

Data

Width

200mm, customized

Thickness

16±1um, customized

Areal density

30~34g/m2

With transverse surface density uniformity

≤0.003 g/ 40×40 mm

The same volume of vertical surface density uniformity

≤0.03 g/ 400×40 mm

High temperature oxidation resistance (200°C*30min)

No oxidation

Connect no

<2

Chemistry content(Al)

>99.45%

Extensibility

<0.5%

Normal temperature Tensile strength

kgf /mm2

>140

After 1200C baking 1h, Tensile strength kgf/mm2

>120

Battery Grade Aluminum Foil Roll

Aluminum Foil for Battery Current Collector

Export Aluminum Foil for Lithium Battery
