Regarding the ABB 086364-001
This is a sensor electronic interface circuit board module for use in ABB industrial automation and control systems.
Its primary function is to serve as an interface between sensor signals and the control system,
processing, conditioning, and transmitting input signals to ensure system stability and reliability.
l Electrical & mechanical quick-check
|
Parameter
|
Factory value
|
Tolerance / note
|
|
Input range
|
0…10 V DC & 4…20 mA
|
jumper-selectable
|
|
Resolution
|
12 bit (4096 steps)
|
monotonic
|
|
Isolation
|
1 500 V RMS
|
channel-to-bus
|
|
Scan time
|
≤ 1 ms
|
all 8 ch.
|
|
Power from rack
|
+24 V DC, 60 mA
|
no ext. supply
|
|
Dimensions
|
147 × 55 × 248 mm
|
matches 0863xx family
|
|
Weight
|
0.24 kg
|
0.13 kg carton only
|
l Which obsolete card can be replaced without re-wiring?
|
Your old ABB part
|
086364-001 fits?
|
Action needed
|
|
086362-001
|
yes (same 8 DI)
|
copy I/O map
|
|
086318-002
|
yes
|
move jumper to “V” position
|
|
086366-004
|
yes
|
re-calibrate scale in DAT tool
|
|
086348-001
|
no (16 DI)
|
use two 086364-001 instead
|
