Technical Brief: ABB AGBB-01C Gate Driver
The AGBB-01C (ABB ID 68242843) is a plug-in gate driver PWA that sits between the control
FPGA and the IGBT modules within the ACS800-104, ACS800-104BV2, ACS800-104C,
and ACS800-104DV2 inverter modules.
AGBB-01C Specs
|
Channels
|
4 (2-level IGBT) /±15 V, ±6 A peak
|
|
Isolation
|
4/kV RMS, IEC 61800-5-1
|
|
DESAT trip
|
7.2/V, auto-reset 20 ms
|
|
Supply
|
3.3 V, 120 mA/from back-plane
|
|
Temp. range
|
–25 … +70°C
|
|
MTBF
|
220/kh @ 45 °C
|
|
Size / weight
|
120 × 120 × 17mm / 0.15 kg
|
AGBB-01C Same family
|
DSMB-01C
|
IGBT power-interface board
|
|
DSCB-01C
|
Fibre-optic signal repeater
|
|
DSAB-01C
|
Capacitor-voltage measurement
|
|
SDCS-CON-4
|
Main control CPU (co-ordinates AGBB-01C)
|
|
AGBB-01B
|
Gate driver, rev-B
|
|
AGBB-01A
|
Gate driver, rev-A
|
