Data Sheet: ABB DSQC223 YB560103-BD DeviceNet I/O Module
Product Identity
DSQC223 (YB560103-BD) is a 16-channel digital I/O board for ABB IRC5 robot controllers. It plugs into the main computer rack and provides 8 DI + 8 DO via DeviceNet, delivering sub-millisecond response for welding, material handling and packaging lines .
Core Technical Data
|
Parameter
|
Specification
|
|
Channel Count
|
8 DI (24 V DC) + 8 DO (24 V DC, 0.5 A)
|
|
Bus Protocol
|
DeviceNet, 125 kbps – 1 Mbps auto-baud
|
|
Response Time
|
≤ 0.5 ms scan cycle
|
|
Supply
|
24 V DC ±20 %, 150 mA typical
|
|
Isolation
|
500 V channel-to-bus
|
|
Operating Temp
|
–20 °C … +70 °C
|
|
Dimensions
|
140 × 100 × 25 mm, DIN-rail clip
|
|
Certifications
|
CE, UL, ATEX Zone 2
|
Quick-Install Features
• Spring-cage terminals accept 0.2–2.5 mm² wire – no ferrules required.
• Hot-swap ready – replace online without stopping the robot.
• LED per channel – instant visual confirmation of signal state.
All components factory-sealed and ready for same-day dispatch from PLC Autocontroller.
|
Function
|
Part Number
|
Note
|
|
I/O Module
|
DSQC223 YB560103-BD
|
This 16-channel unit
|
|
Cable
|
3HAC022643-001
|
2 m DeviceNet drop cable
|
|
Tee
|
3HAC022646-001
|
DeviceNet T-connector
|
|
Terminator
|
3HAC022647-001
|
120 Ω bus terminator
|
|
Power Supply
|
3HAC029157-002
|
24 Vdc DIN-rail 5 A
|
|
I/O Simulator
|
3HAC029157-003
|
Hand-held test box for commissioning
|
