ABB NGDR-07C
Ultra-Compact 24 VDC Digital I/O Relay Module
(Stock-ready at PLC Autocontroller – 20 years of automation speed)
1.30-second snapshot
• 16 configurable inputs or outputs, 24 VDC, 2 A per channel
• 0.1 ms scan, -25…+70 °C, IP20, 35 mm DIN clip
• Plug-in cage-clamp terminals, no tools, swap in <10 s
• CE, UL, cUL, RCM; GSDML file drops straight into TIA Portal, Studio 5000, Automation Builder
2.Why engineers pick NGDR-07C
Space: 22.5 mm wide = 8 modules per meter.
Speed: 0.1 ms delay keeps cycle times under 1 ms on ABB AC500-eCo.
Safety: each channel has electronic fuse + diagnostics LED; fault bit pushed to CPU in <200 µs.
Energy: 1.5 W own consumption, 30 % less heat than legacy 07B.
3.Ordering & logistics
PLC Autocontroller Hongkong keeps >50 pcs on shelf.
Ship today on DHL/UPS before 16:00 CST, 3-5 days worldwide.
OEM box pricing breaks at 10, 50, 100 pcs – ask below.
Table 1 – NGDR-07C quick-spec
|
Parameter
|
Value
|
Note / test condition
|
|
Supply voltage
|
19.2…28.8 VDC
|
SELV, ripple <5 %
|
|
Current / ch
|
2 A resistive
|
derate 40 % for DC-13
|
|
Switching freq.
|
500 Hz max
|
resistive load
|
|
Isolation
|
500 VAC ch-to-bus
|
reinforced, 1 min
|
|
Cable size
|
0.2…1.5 mm² (AWG 24-16)
|
ferrule recommended
|
|
MTBF
|
380 kh @ 40 °C
|
SN 29500, GB
|
Table 2 – Space & energy win vs. NGDR-07B (legacy)
|
Metric
|
NGDR-07C
|
NGDR-07B
|
Saving
|
|
Width
|
22.5 mm
|
45 mm
|
50 %
|
|
Power loss
|
1.5 W
|
2.2 W
|
0.7 W / pc
|
|
Rack slots / 64 IO
|
4
|
8
|
1 rail saved
|
4.Fit-and-forget tips
• Use ABB TK 501 termination kit for 50 % faster wiring.
• Enable “short-circuit latch-off” in Automation Builder → I/O settings; module auto-resets after 1 s.
• For 60 °C cabinets keep 20 mm side-gap; no derating needed up to 70 °C.
5.Download & support
Datasheet, STEP file, GSDML, Eplan macro: bit.ly/NGDR07C-docs
24 h technical hot-line: ab@mooreplc.com (May, English/Chinese)
Need 1 pc for lab or 500 for a line revamp?
Send PO before 16:00 CST, we’ll ship fast.
