One-sentence summary
SDCS-POW-4-SD is ABB DCS800’s flagship power unit that squeezes line rectifier, pre-charge, DC bus and chopper into a 3-U drawer-style module. Slide it in and you have a 4-Q regenerative or 2-Q non-regenerative drive ready to run—250 kW–520 kW stand-alone, 2 MW in parallel, hot-swappable and interchangeable, cutting downtime from days to minutes.
Why field engineers love it
1. Blind-swap design: rail plus fool-proof pin, one person, 15 s, no torque wrench needed.
2. Zero-tool maintenance: quick-release front plate, rotary fuse holder, visual fuse window—inspection done in 2 min.
3. Self-healing fan: individual blade replacement; even if a bearing seizes, airflow continues until the next scheduled stop.
4. Built-in health check: temperature, air-pressure, fuse and thyristor status sent via fibre to the upstream PLC—open a Work Order remotely.
Energy-chain snapshot
|
Role
|
What SDCS-POW-4-SD does inside
|
Value to the system
|
|
Line side
|
6-pulse thyristor bridge + pre-charge contactor
|
380–690 V AC wide range, inrush < 1.5 In, no external soft-starter
|
|
DC side
|
Low-inductance bus-bar + film-capacitor bank
|
Bus ripple ≤ 3 %, 100 % load dump without trip
|
|
Brake side
|
Internal chopper + external resistor terminals
|
100 % rated power continuous braking, duty 5 s ON / 95 s OFF
|
|
Parallel side
|
Fibre optic current sharing + auto-addressing
|
Up to 4 cubicles, current imbalance < 5 %
|
Key boundary data
|
Parameter
|
Value
|
Note
|
|
Rated output current
|
1 000 A @ 40 °C
|
No derating; 120 % 60 s overload built-in
|
|
Short-time current
|
1 500 A / 10 s
|
For fan acceleration or rolling-mill bite
|
|
Protection class
|
IP20 (IP42 hood option)
|
Floor-mounted switch-room, side-in / top-out airflow
|
|
Noise
|
≤ 68 dB(A) @ 1 m
|
Temperature-controlled speed; night mode –6 dB
|
|
Dimensions
|
3 U × 600 mm × 417 mm
|
19" rack compatible; front or rear cable entry
|
|
Weight
|
38 kg
|
11 kg lighter than POW-4; two-person lift
|
Typical snap-shots
High-speed wire rod finishing: at 75 m/s tail-out, DC-bus voltage sag < 2 %—no trip, no strip break.
Shipboard deck winch: 690 V ship supply variation +15 %/–20 %; POW-4-SD auto-triggers “weak-grid mode” and keeps constant tension.
Hot-strip mill F1–F7: 7 units in parallel, 6 MW total. Roll change time 15 min; power modules slide out with the roll rack, maintenance shift cut by 40 %.
20 years channel, 1-hour quotation
PLC Autocontroller’s Xiamen warehouse keeps complete units and wear parts (thyristors, fuses, fans, capacitor boards) on the shelf. Order today, ship today. “Swap-first, repair-later” service: faulty unit back to us, inspection report and repair quote within 48 h—your spares budget stays transparent and controllable.
