advanced core patented technology
|
|
high safety, triple anti-pinch
|
|
high stability, optimize the mechanism structure
|
|
long life, longer than 10 million times
|
|
|
|
|
|
|
|
|
|
accurate & fast detection
|
|
high visitor flow rate usage
|
|
modular design, easy maintenance
|
|
high compatibility, high integration
|
All-around Pedestrian Safety Protection
Turnstile opens when power failure
With the independently developed advanced mechanical structure, the system will automatically unlock the gate when the power is off, and the gate can be manually pushed to open, which is convenient for pedestrian evacuation.
Triple anti-clamping
With triple anti-clamping technologies such as infrared anti-clamping, mechanical anti-clamping and anti-collision by advanced electric current detection, the access control speed gate turnstile auto system can protect pedestrian safety more comprehensively.
Over-force feedback control
When the gate is momentarily subjected to an impact force beyond the safe range, the gate can be slowly pushed for a certain distance to buffer the impact force on the mechanism and the reverse impact force on pedestrians.
Emergency open
The access control speed gate turnstile auto system equips with emergency escape control device, to make the system automatically open the gate to evacuate pedestrian.
Anti-electric shock
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current protective device to prevent pedestrian from being injured by electric shocks.
Advanced & Intelligent Turnstile Core Technology
Long service life
The mechanism and control system of access control speed gate turnstile auto system have been passed 10 million times life test.
Strong mechanism structure
CMOLO's self-developed lossless modular mechanism structure and full CNC processing technology are to ensure that the precision, strength and concentricity of the mechanism. The transmission ratio is accurate, efficient and stable, and the rotation angle of the gate can be precisely controlled and the loss is reduced, so as to ensure the stability and long service life of the mechanism structure.
Advanced core logic algorithm
The access control speed gate turnstile auto system adopts advanced servo control system and DSP+ARM motor control technology, combined with the motor control algorithm independently developed by CMOLO, which can achieve precise control and positioning of the obstacle and maintain stable performance.
The turnstile auto system adopts CMOLO® patented passing detection algorithm and matrix photoelectric stereo detection technology, to sensitively detect illegal behaviors such as reversely passing and tailgating, and issues warnings in the form of sound and light, and can be linked with other security systems.
Customization
| Appearance |
Cabinet size, material and surface treatment process etc. of turnstile can be moderately customized. |
| Lane width |
The maximum lane width of turnstile is 900mm, and the cabinet length can be increased accordingly |
| Material of the gates |
Tempered glass / acrylic / polycarbonate, and color can be customized. |
| Direction Indicator |
The installation position of direction indicator can be adjusted.
The shape of direction indicator can be customized. |
| System integration |
Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.
Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.
Integrate with card collection system, and customize card collection device
|
Function
|
Built-in or external counter
TCP / IP communication function
Audible and visual alarm function
|
