Automatic Horizontal Type Strapping Packing Machine

The horizontal strapping machine utilizes front and rear powered roller devices, achieving fully automatic, unmanned operation.  The perfectly designed belt effectively solves the off-center problem, significantly extending the belt's lifespan. The powered rollers are driven by motors, and the work surfaces operate independently, making daily maintenance more convenient. The machine core and standard components are interchangeable, ensuring easy and quick maintenance.



Automatic Horizontal Type Strapping Packing Machine (Model: DBJ1200H)

The products meet the requirements of continuous and reliable strapping, the plastic straps are tightly applied to the surface of the packages, the joints are secure, the machine's electrical system is safe, and the working noise and fumes do not affect the health of the operators.



Parameter Information:

Item DBJ1200H
Equipment Dimensions (W) 3200 x (L) 1800 x (H) 3400 mm(Customizable)
Maximum Strapping Force 3500N (adjustable)
Power 3.5KW
Strapping Speed 2-4.2 m/sec (adjustable)
Welding Speed 0.3-1.5 sec (adjustable)
Welding Method High-frequency friction (pneumatic/electric)
Strapping Material PET strapping tape
Strapping Tape Specifications Width (12-16mm) x Thickness (0.5-0.8mm)
Packaging Width 1m (length) x 1m (width), customizable
Packaging Height 0.7-1.6m (automatically recognized within this range), customizable



Product Advantages:

1.Adopts a dual-motor digital intelligent strapping head;

2.Simple structure, easy maintenance, stable performance,

3, Works with various strap types, no strap breakage,

4, Strapping force can be digitally adjusted, maximum strapping force of 350 kg.



Application:
