Automatic Oral Liquid Syrup Filling and Capping Machine
Brief Introduction:
Oral Liquid Syrup Filling and Capping
Machine has the functions such as Oral Liquid Syrup Filling and Capping Machine
has the functions such as automatical screw type bottle feeding, bottle
detecting (no bottle no filling, no bottle no cap feeding ), filling, cap
feeding and capping automatically.
Features:
The singe (double) head automatic ointment
filling machine adopts programmable logic controller (PLC) human and machine
interface technology, equipped with imported photoelectric track switch from
Korea, which is suitable for filling ointment products in the industries such
as ointment, oil products, syrup, shampoo, bechamel and fruit juice etc. The
filling nozzle will be automatically inserted into the bottle to carry out the
filling and then rapidly ascend, which can reduce the air bubbles. The product integrates
electric and pneumatic functions into one, with reasonable design, stable
performance, accurate quantity, glass table surface, automatic bottle feeding,
steady operation without noise, electric speed control to the filling speed and
filling volume and convenient maintenance and cleaning. The new type filling
equipment is the best choice for the realization of automatic production.
Main Parameter:
|
Model
|
Unit
|
SMF
|
|
Filling volume
|
Ml
|
5-250
|
|
Production capacity
|
Bottle/h
|
1000-3000
|
|
Quantitative error
|
%
|
≤±1%
|
|
Cap feeding rate
|
%
|
≥99％
|
|
Capping rate
|
%
|
≥99％
|
|
Source voltage
|
V
|
Three-phase four-wire system AC220V 380V ±10%
|
|
Consumed power
|
KW
|
1
|
|
Gas supply pressure
|
MPA
|
0.4-0.6
|
|
Air consumption
|
M3/min
|
0.2
|
After-sales Service:
(1) Under stable voltage, the machines' quality that we sold will be guaranteed for 2 year
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets, accommodation, and your side traveling fee will be charged by you. Engineer's salary will be USD100.00/day/person.
We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
