Applications:
beiben 3134 truck ,also
called as beiben 12 wheeler truck, beiben 8*4 drive truck, north benz 12 wheeler truck NG80B truck, beiben 3134 truck chassis is designed
for producing beiben 30,000 liters fuel truck, beiben 30 T wrecker truck, beiben 60 T heavy duty dump trucks, beiben 12 wheeler cargo truck. This beiben truck chassis can loading, transporting and discharging heavy duty material , also can
be used in for earth, sand, rock and mining delivery.
Congo beiben 12 wheeler truck chassis apply germany benz technology device, with extremely work performance.
The cargo truck Box material optional: Manganese steel & Carbon steel, which is safe and durable.
Key Features:
---- North benz 3134 chassis, strong military driving system
---- Military quality assurance, Original germany benz technology
---- Extremely work service , long terms maintenance
---- Patented axle technology, with wheel reducer
---- Completely steel cabin , safety and reliable.
Specifications:
| Beiben 3134 truck chassis
|
| General
|
Vehicle Brand
|
CEEC TRUCKS
|
| Chassis Brand
|
Beiben
|
| Overall Dimension
|
10500*2490*3340 mm
|
| GVW / Kerb Weight
|
45,000 kg / 14,800 kg
|
| Cab
|
Cab Capacity
|
2 persons allowed
|
| Air Conditioner
|
Heating/cooling air conditioner
|
| Engine
|
Fuel Type
|
Diesel
|
| Engine Brand
|
WEICHAI
|
| Power
|
340 HP (250 KW)
|
| Displacement
|
9726 ml
|
| Emission Standard
|
Euro 3
|
| Chassis
|
Drive Type
|
8X4, (left hand drive)
|
| Transmission
|
FAST 9 speed levers with 1 reverse
|
| Wheelbase/No. of axle
|
1950+5050+1450 mm / 4
|
| Tire Specification
|
12.00R20
|
| Tire Number
|
10 tires and 1 spare tire
|
| Max Speed
|
90 km/h
|
| Paint
|
Metallic paint
|
| Superstructure
|
Body Capacity
|
40 T- 80 T
|
| Tilting Device
|
Front lifting device
|
| Hydraulic Cylinder
|
China brand
|
| Discharging model
|
Rear discharging
|
Dump Body Dimension
|
7600*2300*1500 mm |
| Thickness
|
Side Board: 8mm
Floor Board: 10 mm
|
| Control panel
|
English or Your language
|
| All standard accessories: basic tool kit, English manual……
|
| Optional
|
** Back alarm and Camera can be equipped.
** Italy mulit-valve can be choose.
** 12.00-24 tyre, 14.00R20 tyre, 13.00R22.5 tyre avaiable.
|
Beiben 12 wheeler truck chassis , can be produced beiben 30 T cargo truck
beiben 3134 truck, with china beiben updated technology.
