Product Overview

Model 990-08 - XX - 01-00 is a two-wire (loop - powered) vibration transmitter in the Bently Nevada 990 series. Designed to convert mechanical vibrations (peak-to-peak vibrations) approaching a probe (such as a 3300 NSv probe) into a standard 4-20  mA analog signal. It is suitable for vibration monitoring and alarm in industrial control systems (PLC/DCS).

Key parameters and specifications

v Model: 990-08 - XX - 01-00

v Series: 990 Vibration Transmitter

v Range (full-scale) : 0-8 mils pp (~0-200 µm pp)

v System length options (XX) : Common ones include 5 m (50) / 7 m (70), etc

v Installation method: 35mm DIN rail clamp

v Supply voltage: +12 to +35 V DC

v Output signal: 4-20 mA

v Frequency response: 5 Hz to ~6000 Hz ±0.3 dB

v Humidity/Environment: Supports high-humidity environments

v Connector/Diagnostic: There are "PROX OUT" + "COM" terminals for dynamic signals

Product advantages

Ø Integrated Proximitor: Built-in Proximity function, no need for external converters, simplifying system design.

Ø Standard analog output: 4-20  mA output, facilitating integration with industrial control systems (PLC/DCS).

Ø High environmental adaptability: Supports high humidity (100% condensation) and a wide temperature range (depending on the version).

Ø On-site diagnostic capability: Dynamic probe signals can be output through the PROX OUT terminal for fault diagnosis.

Ø Flexible installation: DIN rails are easy to install (for some models), suitable for compact Spaces.

Ø Easy adjustment: The external Zero (Zero) and Span (Span) potentiometers (non-interactive type) are adjustable

Order & ship

u Xiamen stock, 1 Year Warranty

u 100% Original Package

u UPS/ DHL/ FEDEX / TNT
