Specification:

Control component

Display

7" LCD, resolution: 1024*600

Operation

Multi-Touch,Capacitive Touch Panel

SOC

Quad-core, integration GPU, 1.6GHZ

RAM

DDR3,1GB

ROM

1~2GB

Flash

Built-in 8G

TF card

1-32G

Ethernet

100M (IEEE 802.3u)

USB

4*USB DSB OTG 2.0

WI-FI

Built-in WIFI (IEEE 802.11 b /g/n)

Bluetooth

Built-in BlueTooth (Bluetooth 4.0)

3G

Huawei E1220S (Huawei normal USB communication module)

Paper

Paper type

Thermal paper roll / adhesive thermal paper

Paper width

20~60mm

Paper diameter

110mm max.

Print

Printing mode

Direct thermal line

Dot density

203DPI

Print speed

Max 127mm/s; Min 101mm/s

Print width

2 inch

Paper cutting way

Tear off

Print head temperature detect

thermal sensitive resistance

Print headposition detect

Microswitch

Paper sensor

Photoelectricity

Barcode type

CODE128,EAN128,ITF,CODE39,CODE93,EAN13,EAN13+2, EAN13+5, EAN8,EAN8+2, EAN8+5, CODABAR,POSTNET,UPC-A,UPCA+2,UPCA+5,UPC-E,UPCE+2,UPC-E+5,CPOST,MSI,MSIC,PLESSEY,ITF14,EAN14

Character font

Font 0 ~ Font 8

Character enlargement & rotation

1-10 times enlargement in horizontal and vertical directions;

Rotation printing  (0°, 90°, 180°, 270°, 360° )


Single color PCX, BMP image file can be download into Flash and Dram

Dimension

195*115*180mm(L*W*H)

Weight

1.2kg

Power

Power supply

DC 12V/5A

Environment

Work environment

Temperature 5~45℃; Humidity 20~80%RH

Storage environment

Temperature -10~50℃; Humidity≤93%RH(40℃)
