Dimensions :
|
DIMENSIONS
|
|
TARE WEIGHT
|
11000KG
|
PAYLODA
|
40000KG
|
|
overall
|
12000mm
|
overall width
|
2500mm
|
overall height
|
4000mm
|
Specification :
|
SPECIFICATION
|
|
TANK body
|
q235a/6mm
steel sheet shape：V type
|
|
END PLATE
|
q235a/6mm. ball
shape
|
|
AXLE
|
number
|
3
|
brand
|
optional upon
choice
|
capacity
|
13t
|
|
suspension
|
mechanical
suspension or Air suspension
|
|
leaf spring
|
leaf spring or Air bag
|
|
manhole cover
|
500mm manhole
cover .2sets
|
|
tire
|
11.00r20，12.00r20，11r22.5，315/80r22.5 tire optional
|
|
wheel rim
|
8.5-20,8.25-20,9.0-22.5,steel
wheel rim optional upon choice
|
|
discharge valve
|
4''disc valve
|
|
dischargepipe
|
4''seamless
steel tube
|
|
kingpin
|
2''/3.5''bolt-in
kingpin
|
|
landinggear
|
jostbrandtwo-speed， manualoperating，heavy duty
landing gear
|
|
engine
|
diesel engine or
electrical motor
|
|
air compressor
|
37 kw，0.2mpa.100r/min
|
|
compartment
|
single
|
|
braking system
|
wabco re6 reay
valve：t30/30spring brake chamber：40l air tanks
|
|
painting
|
complete chassis
sand blasting to clean rust，1cpat of
anticorrosive prime， 2coats of final
paint
|
|
accessories
|
one standard
tool box
|
|
air-charging system
|
2''main hole，2''checkvalve，1.5''safe valve，0.4map gauge
|
|
quadratic blow
|
1''diameter
check valve
|
|
qutlet discharge pipe
|
4''rubber
hose.6m
|
