Dimensions :
|
DIMENSIONS
|
|
Tare weight
|
4700KG，9200KG
|
Total volume
|
24/48CBM
|
|
Specification :
|
Chassis
|
Heavy duty and
extra durability designed i beam；opting for
high tensile steel Q345，welded by automatic subrnerged-Arc processes. Top
flange 14mm，width 140mm；Middle Flange 8mm；bottom
flange16mm，width 140mm
|
|
Tanker body materia
|
Q235A/5mm
|
|
End plate
|
Q235A/5mm ，by punching
|
|
Tanker shape
|
Tanker shape can
be of various designs and contractions. All tankers are designed to suit sea
transportation requirement
|
|
Manhole cover
|
Aluminum alloy
APImanhole cover， 500mm，2 sets with 2 breather valves
|
|
Bottom valve
|
1-2 sets of
Aluminum API Pneumatic bottom valve
|
|
Discharging
valve
|
2-4 sets 100mm Discharging valves
|
|
Discharging pipe
|
4”rubber，2 pcs， 6m long
|
