Features
|
|
1. Long communication distance; 15m indoor and 15-30m outdoor
|
|
2. Mulitple interface, support USB (standard), RS232 (optional)
|
|
3. Full quakeproof, waterproof, dustproof, antiknock design
|
|
4. IP67 Industrial Grade, drop lots of time from 7 high
meters still work normally, work under water for more than 30 minutes
|
|
5. Free of charging trouble; battery lasts 6-10 hours after full charged; base functions as receiver and charger.
|
|
Applicable scope
|
|
1. Comercial POS system(Supermarkets)
|
|
2. Warehousing and logistics
|
|
3. Libraries
|
|
4. Banks and Telecom
|
|
5. Transportaion
|
|
6. Postal service
|
|
7. Industrial and manufacturing management
|
|
Feature
|
|
Light Resource
|
C C D (Safe visible light)
|
|
Port/Interface
|
USB (standard), RS232 (optional)
|
|
Supported Symbologies
|
EAN-13, EAN-8, UPC A, UPC E, CODABAR (NW-7), Code 39, Code93, Interleaved 2 of 5,
Standard 2 of 5, Matrix 2 of 5, Code 128 EAN/UCC 128, Code 11
|
|
Scans per charge
|
30000 times
|
|
Presicion
|
≥4 mil
|
|
Depth of scan field
|
Code 39 70mm~190mm(5mil)
|
|
Ean-13 50mm~450mm(13mil)
|
|
Code128 45mm~430mm(10mil)
|
|
Battery capacity
|
2000MAH
|
|
Charging time
|
3~4 hours
|
|
Decode speed
|
260times/ second
|
|
Decode Error Rate
|
less than 1/8 million
|
|
Print Contrast Signal
|
≥30°
|
|
Scan Angle
|
Yaw(Skew) 45° pitch 60°
|
|
Safety
|
Full quakeproof, waterproof, dustproof, antiknock-design
|
|
and EMI Shielding
|
|
Mechanical/ Electrical
|
|
|
Working Voltage
|
DC 3.3V
|
|
Current
|
Maximum current :150mA
|
|
Standby current: 45mA (RS232）
|
|
Sleep current :54.0mA(USB)
|
|
Rated power consumption
|
0.33W
|
|
Environmetal
|
|
Operation Tempereture
|
-20℃-45℃
|
|
Storage Temperature
|
-20℃-45℃
|
|
Humidity
|
5%-85%
|
|
Certifications
|
CE, IP67，ROHS, FCC ，EMC , RED, LVD
|
|
|
|
