Cisco GLC-BX-20D Compatible 1000BASE-BX BiDi SFP 1550nm-TX/1310nm-RX 20km DOM Transceiver Module

Cisco GLC-BX-20D Compatible 1000BASE-BX SFP Transceiver Module (SMF, 1550nm-TX/1310nm-RX, 20km, LC, DOM) compatible with Cisco Nexus 9300 Series (Switch/Module : N9K-C9396PX; Uplink Module : N9K-M12PQ ), Cisco ASR 9000 Series (Modular Line Card : A9K-MPA-20X1GE), etc.

  • ConnectorLC simplex
  • WavelengthTx1550/Rx1310nm
  • Temperature0 to 70°C
  • Data Rate155M
  • Distance20km
  • Warranty1 Year
Facebook Twitter Pinterest LinkedIn 分享

Cisco GLC-BX-20D Compatible 1000BASE-BX BiDi SFP 1550nm-TX/1310nm-RX 20km DOM Transceiver Module


Features

  • Transceiver unit with independent
  •  FP laser transmitter and PIN photo-detector
  •   Dual Data-rate of 1.25Gbps/1.0625Gbps Operation
  •  Up to 20KM transmission distance on 9/125μm SMF
  •  Standard serial ID information compliant with SFP MSA
  •  SFP MSA package  with duplex LC connector
  •  Digital Diagnostic Monitor Interface
  •  Very low EMI and excellent ESD protection
  •   +3.3V single power supply
  •   Wide operating temperature range
  •   RoHS compliant
  •  Case operating temperature Commercial: 0°C to +70°C Extended: -10°C to +80°C Industrial: -40°C to +85°C
