Product name:Commercial Party Canopy Tents 20x20
Party Tent 20x20 's Application:
Widely used for temporary outdoor exhibitions, wedding parties, festival celebrations, conferences, sports and other events, and also good solution of temporary warehouse, workshop and temporary emergency relief and other purposes.
|
Aluminum Structure
|
Hard pressed extruded aluminum 6061/T6, anodized surface finishing
|
|
High Performance Fabric
|
Double PVC coated polyester fabric, 750g-850/sq.m, water proof,
UV resistance, anti-mildew, fire retardant to DIN4102 B1/M2
|
|
Eave Connections
|
Hot-dip galvanized steel
|
|
Main Frame Profile
|
300*120*5mm
|
|
Safety Parameters
|
Wind load: 100km/h
|
The specification of Party Tent 20x20:
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
BS10/4-5
|
10
|
4
|
5.5
|
5
|
18°
|
6
|
100
|
|
BS15/4-5
|
15
|
4
|
6.4
|
5
|
18°
|
8.5
|
100
|
|
BS20/4-5
|
20
|
4
|
7.1
|
5
|
18°
|
10.7
|
100
|
|
BS25/4-5
|
25
|
4
|
7.9
|
5
|
18°
|
10.7
|
100
|
The accessories of Party Tent 20x20:
