Product Introduction
The handheld unmanned aerial vehicle (UAV) detection device ZC-04 adopts a highly integrated and low-power design. It is capable of detecting mainstream UAV on the market as well as various types of FPV drones that use analog video transmission signals. The device is equipped with dual antennas and a multi-channel synchronous scanning mechanism, and featuring fast detection speed, high sensitivity, long detection distance, and low false alarm rate. It is easy to operate and suitable for security scenarios such as parks and large-scale events.
Product features
Support multilingual switching between English and Russian
Equipped with alarm log recording and the logs can be exported via the USB interface
Headphone sound alarm, external sound and light alarm
Display the working status of the device such as time and battery level
Technical parameters
|
ZC-04
|
|
Size
|
≤135mm*60mm*35mm (main unit without antenna)
|
|
Weight
|
≤500g(including single battery)
|
|
Frequency band
|
300MHz~6200MHz
|
|
Identification type
|
OFDM high-definition video transmission signal, FPV analog video transmission
|
|
Detection distance
|
≥1km
|
|
Detection sensitivity
|
Better than -96dBm
|
|
Detection and alarm method
|
Headphones, sound and light
|
|
Log recording
|
Support no less than 500 alarm records
|
|
Upgrade and data export interface
|
Type-c
|
|
Power supply
|
Detachable lithium battery (type-c charging)
|
|
Battery life
|
≥6 hours (single battery)
|
|
Startup mode
|
Rotate the button to start
|
|
Control method
|
Key operation, supporting sound adjustment
|
|
Screen backlight activation and drone detection information viewing function
|
|
The above parameters are for reference only. The detailed product parameters are subject to the actual delivery.
|
