Dimensions :

Tare  weight

15000kg

Payload

60000kg

Overall  Length

11000mm

Overall  Width

2500mm

Overall height

3500mm


  Specification :



SPECIFICATION

Chassis

Heavy duty and extra durability designed i beamopting for high  tensile steel Q345welded by automatic subrnerged-Arc processes. Top flange 16mmwidth 200mmMiddle Flange 8mmbottom flange16mmwidth 200mm

Axle

Number

3

Brand

Optional upon choice

Capacity

13T

Suspension

Mechanical suspension Or air suspension

Leaf spring

Leaf spring or air bag

Floor

3mm bottom plate.side wall 2mm

Tire

11.00R2012.00R2011R22.512R22.5315/80R22.5 Tire optional

Wheel rim

8.5-209.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice

Kingpin

2”/3.5”bolt-in king pin

Landing gear

JOST brand two-speedmanual operationheavy duty landing gear

Vehicular applications

Cargos transport

Braking system

WABCO RE6 relay valveT30/30 sping brake chamber40L air tanks

Painting

Complete chassis sand blasting to clean rust1coat of anticorrosive prime2coats of final paint

Accessories

one standard tool box
