Corrugated Cardboard Making Machine of Model K8 Fixed Structure
Corrugated Cardboard Making Machine Features：
·This machine is designed and made to high quality and safety standard,with the advantages of high speed, auto control and quick order shift.
·Auto high quality materials and parts.
·Well hardened and ground transmission gears, hardness more than 60(HRC).
·Vacuum transfer system used in all printing sections.
·Use expansion sets tight link to reduce abrasion of the shaft,keep precision of the machine for long years.
·PLC control system with touch screen control.
·Able to save order,speed up the order shift.
·All electronic and pneumatic components are with European standards.
·Able to shift order of the idle Printing Section under production.
·Able to facilitate the production management.
Cost of Cardboard Making Machine Specification：
|
Data/Model
|
900x2000
|
900x2400
|
1200x2000
|
1200x2400
|
|
Printing Speed(m/min)
|
200
|
200
|
200
|
200
|
|
Max Machine Speed(pcs/min)
|
350
|
300
|
250
|
250
|
|
Max Feeding Size(mm)
|
880x2000
|
880x2400
|
1180x2000
|
1180x2400
|
|
Min Feeding Size(mm)
|
280x640
|
280x640
|
320x700
|
320x700
|
|
Skip Feeding(mm)
|
1100x2000
|
1100x2400
|
1500x2000
|
1500x2400
|
|
Max Printing Area(mm)
|
800x2000
|
800x2400
|
1150x2000
|
1150x2400
|
|
Thickness of Printing Plate(mm)
|
7.2
|
7.2
|
7.2
|
7.2
|
|
Min Panel(mm) Slot Type L.
|
240x80x240x80
|
240x80x240x80
|
260x90x260x90
|
260x90x260x90
|
|
Max Slotting Depth(mm)
|
250
|
250
|
320
|
320
|
|
Max Thickness of Sheet(mm)
|
8
|
8
|
12
|
12
|
|
Dimension(LxWxH)
T
F
|
T:14374x5770x3200
F:15674x5770x3200
|
T:14374x6170x3200
F:15674x6170x3200
|
T:15732x5870x3500
F:17232x5870x3500
|
T:15732x6270x3500
F:17232x6270x3500
|
Our Company:
Guangzhou Keshenglong Carton Packing Machine Co.,Ltd., is one of the leading manufacturers in China, specialized in manufacturing of carton printing and packaging machinery.
Our products have been exported to more than 70 countries.
For the time being, we have more than 300 employees in our team, and have our own R&D, manufacturing, sales and after-sales service department, with our strict production and experienced construction team, taking the professional route and providing one-stop service for our customers.
