80mm Serial+USB+LAN thermal receipt pos printer
CSN-80V pos receipt printer is a compact,fast and advanced receipt pos machine printer, and bar code printer. enabling you to produce high quality receipts quickly and easily. With an easy maintenance cutter and patented long life printing (LLP) technology, capable of extending print life to over 100km.Features include drop-in paper loading, RS232,USB,LAN three ports, auto cutter and a long life thermal print head.
Feature:
1). High printing speed, up to 250mm/s, easy to maintain, improve work efficiency.
2). Low noise, high speed image&characters printing
3). Easy paper loading, with auto cutter,partial cut
4). Serial/USB/Ethernet interface optional.(Support two in one, or three in one)
5). Compatible with EPSON ESC/POS command sets.
6). Support paper out alarm and print prompt
7). Driver compatible: Win2000/WinXP/Windows7/Windows10/Linux
Specification:
| Model No. |
CSN-80V |
| Print Method |
Thermal line printing |
| Print Speed |
Max.250 mm/sec |
| Effective Print Width |
72mm |
| Thermal paper roll |
Paper width:80mm |
| Max.80mm(O.D) |
| Paper thickness:0.055-0.09mm |
| Resolution |
203dpi |
| Reliability |
TPH life:100km |
| Cutter life:1 million cuts or more |
| Character size |
(ANK Character):12×24 dots,1.5(width)×3.00(height)mm |
| (Jan/traditional form):24×24 dots,3.00(height)×3.00(high)mm |
| Characters Set |
ANK:Font A:12x24dots |
| Font B:9x17dots |
| Jan/traditional form:24x24dots |
| Barcode type |
UPC-A,UC-E,JAN13(EAN13),CODABAR,ITF,CODE39,CODE93,CODE128 |
| PDF417,QR Code |
| Memory flash |
8M bytes |
| Interface |
RS232C+USB+LAN |
| Auto-Cutter |
Full cut and Partial cut by command |
| Cashbox Control |
24V/1A |
| Power supply |
DC24V/2.0A |
| Printing command |
Compatible with ESC/POS command set |
| Dimension (WxLxH) |
148x198x145mm |
| Work environment |
Temperature 0°C~45°C;Relative humidity:10%~80% |
| Store environment |
Temperature-10°C~60°C;Relative humidity:10%~90% |
| Driver/SDK |
Windows Driver, Linux Driver, Android SDK, Windows SDK |
Company Information:
We are a professional manufacturer of thermal printers since 2011.Our main products are handheld thermal printer, impact dot matrix printer, panel thermal printer, kiosk ticket printer, pos printer and label barcode thermal printer, etc. We have a wealth of in dependent research and experience, which can effectively meet different customers ODM requirements and help achieve printing simply, efficiently and economically. Currently, Our products are exported to Southeast Asia, South Asia, South & North America, Middle East and Europe, etc.
FAQ:
Q: About samples
A: Samples are available for testing.
Q: Delivery date.
A: All the printers for samples are in stock, can ship it within 2 days after payment received. For bulk order
delivery date approximately 2 weeks.
Q: Payment terms
A: Paypal, western union, T/T in advance.
Q: Warranty
A: One year warranty. During warranty period, the damage caused by non-human factor, CASHINO will be
responsible for the free repair. Overdue warranty period, CASHINO will continue to provide services with
reasonable price to the customer.
