Features
l ISO 18000-6C/6B, EPC Global C1G2 /C2G2 supportable UHF RFID transceiver
l Multiple interfaces help to accelerate system development speed
l Seamlessly compatible with RFID middleware
l Fully interoperable in different global regulatory environments such as US, EU, GB
l Different developing languages SDK meet different developer needs
l Widely used in professional ODM / OEM split-type ＆ integrated type RFID reader / writer
Specifications
Hardware, OS and Firmware Management
|
Processor
|
ARM9, 400MHz
|
Operating System
|
Linux 2.6
|
Firmware Upgrade
|
Demo software / Telnet
|
API Support
|
Windows – .NET, C++ and Java SDK
Android - Java
Linux platform – C and Java SDK
|
Physical Characteristics
|
Dimensions
|
105mm×95mm×18mm
|
Weight
|
0.2Kg
|
Antenna Port
|
2*SMA-female
|
RFID Characteristics
|
Air Protocols
|
ISO/IEC18000-6B,6C / EPC C1Gen2
|
Chipset
|
Impinj Indy R2000
|
Frequency
|
865MHz-928MHz
|
Programing Functions
|
Automatic reading/ White list
Breakpoint Resume / Match reading / Data filter
|
Output Power
|
0dBm-30dBm(±1dBm) adjustable
|
Reading Distance
|
0-20m(According to antenna & application)
|
Connectivity
|
Communications
|
RJ45, RS-232, RS-485, Wiegand, GPIO
|
Power supply
|
DC 24V/2.5A (DC 9V ~ 30V,30W)
|
Environmental
|
Operating Temp.
|
-20 - +50°C
|
Storage Temp.
|
-30 - +50°C
|
Interface Definition
RJ45 Interface Definition form
Line sequence
|
Color
|
Definition
|
1
|
White, green
|
Ethernet data Transmit +
|
2
|
green
|
Ethernet data Transmit -
|
3
|
White, orange
|
Ethernet data Receive +
|
4
|
Blue
|
VCC 24V
|
5
|
White, blue
|
Ground
|
6
|
Orange
|
Ethernet data Receive -
|
7
|
White, brown
|
RS485 +
|
8
|
Brown
|
RS485 -
|
RS232 Interface Definition form
Line sequence
|
Definition
|
1
|
NC
|
2
|
RXD
|
3
|
TXD
|
4
|
NC
|
5
|
GND
|
6
|
NC
|
7
|
GPI1
|
8
|
GPO1/Wiegand 0
|
9
|
GPO2/Wiegand 1
|
