Model No.:
|
YX-P5
|
|
Pixel pitch:5
|
mm
|
|
LED encapsulation:
|
SMD2525
|
|
Resolution:
|
40000dots/m2
|
|
Brightness:
|
≥6000nit
|
|
Cabinet size:
|
960x960x95mm
|
|
Cabinet weight:
|
12.5kg
|
|
Average powe consumption:
|
≤600w/m2
|
|
Best viewing angle:
|
H:160° V:120°
|
|
Refresh rate:
|
360-4800Hz
|
|
Grey scale:
|
14-16bit
|
|
Best viewing distance:
|
1.5-50m
|
|
Protection Level:
|
IP31
|
|
Cabinet Material:
|
Die-casting Aluminum
|
|
Operating Voltage:
|
AC220V/50Hz
|
Quick Detail:
1. SMD2525 black LED;
2. 320× 160 mm LED module;
3.960 × 960 mm cabinet;
4. 192× 192 pixels cabinet resolution;
6. 1,920 Hz refresh rate.
7.It is equipped with 1 pc power supply and 1 pc receiving card per cabinet;
8.2 years warranty is provided for LED module.
Application:
Such LED screen is used for rental like shows, concert, and so on.
