1. Features
High air intake system, dual air filtration
system design, More conducive to the protection of the engine.
With drum brake and vacuum booster form,
makes braking more lightweight and sensitive.
V-type engine feet layout to effectively
reduce engine vibration, a more comfortable ride.
Use of self-lubricating bearings at the
kingpin to improve life of bearing and kingpin.
Use of 10 t main reducer and
transaxle case structure (patented technology), to enhance the carrying capacity
of the drive axle
2. Specification
|
Model
|
CPCD40
|
CPCD45
|
CPCD50S
|
CPCD50
|
|
1
|
Feature
|
Power Type
|
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
|
2
|
Load Capcity
|
kg
|
4000
|
4500
|
5000
|
5000
|
|
3
|
Load center
|
mm
|
500
|
500
|
500
|
600
|
|
4
|
Lift height
|
mm
|
3000
|
3000
|
3000
|
3000
|
|
5
|
Free lift height
|
mm
|
110
|
150
|
150
|
205
|
|
6
|
Forkk size
|
L*W*H
|
mm
|
1070×150×50
|
1070×150×50
|
1070×150×50
|
1220×150×55
|
|
7
|
Mast tilt
|
FR/RR
|
。
|
6/12
|
6/12
|
6/12
|
6/12
|
|
8
|
Min turning Radius
|
mm
|
2835
|
2750
|
2970
|
3300
|
|
9
|
Min Right angle stacking aisle width
|
mm
|
4525
|
4695
|
4915
|
4930
|
|
10
|
Min right angle aisle width
|
mm
|
2862
|
2612
|
2678
|
2960
|
|
11
|
Min ground clearance
|
mm
|
138
|
150
|
150
|
210
|
|
12
|
Height of overhead guard
|
mm
|
2140
|
2265
|
2265
|
2450
|
|
13
|
Overhang
|
mm
|
490
|
547
|
547
|
590
|
|
14
|
Performance
|
Max driving speed
|
Full load
|
km/h
|
20
|
19
|
19
|
26
|
|
15
|
Max Lifting speed
|
Full load
|
mm/s
|
380
|
500
|
410
|
370
|
|
16
|
Max drawbar pull
|
Full load
|
KN
|
21.8
|
40
|
47
|
53
|
|
17
|
Gradeabiity
|
%
|
15
|
20
|
20
|
15
|
|
18
|
Dimension
|
Overall length
|
Without forks
|
mm
|
2950
|
3102
|
3202
|
3440
|
|
19
|
Over width
|
mm
|
1410
|
1480
|
1480
|
1995
|
|
20
|
Height mast lifted(with backrest）
|
mm
|
4220
|
4425
|
4425
|
3930
|
|
21
|
Height mast lowered
|
mm
|
2120
|
2230
|
2230
|
2500
|
|
22
|
Chassis
|
Tyre
|
Front
|
|
250-15-16PR
|
2-300-15-20PR
|
2-300-15-20PR
|
8.15-15-14PR
|
|
23
|
Rear
|
|
6.50-10-10PR
|
2-7.00-12-12PR
|
2-7.00-12-12PR
|
8.15-15-14PR
|
|
24
|
Wheelbase
|
mm
|
1900
|
2000
|
2100
|
2250
|
|
25
|
Tread
|
FR/RR
|
mm
|
1160/1065
|
1182/1202
|
1182/1202
|
1470/1700
|
|
26
|
Self weight
|
Without load
|
Kg
|
5205
|
6550
|
7000
|
8160
|
|
27
|
Drive
|
Battery
|
Voltage / Capacity
|
V/Ah
|
12/80
|
24/80
|
24/80
|
24/160
|
|
28
|
Engine
|
Model
|
|
XC A498BPG
|
YT-LR4B3-22
|
XC4110
|
CA6110/125-JHG10
|
|
29
|
Rated Power
|
kw/r.p.m
|
45/2500
|
57/2200
|
61/2200
|
83/2200
|
|
30
|
Rated Torque
|
Nm/r.p.m
|
198/1800
|
305/1700
|
305/1500
|
432/1300
|
|
31
|
Bore * sTROKE
|
mm
|
98×105
|
108×125
|
110×125
|
110×125
|
|
32
|
No.of Cylinder
|
|
4
|
4
|
4
|
6
|
|
33
|
Displacement
|
L
|
3.168
|
4.58
|
4.75
|
7.127
|
|
34
|
Fuel tank capacity
|
L
|
66
|
90
|
110
|
110
|
|
35
|
Transmission
|
|
1/1manual shift
|
2/1manual shift
|
2/1manual shift
|
2/2manual shift
|
|
36
|
Operating Pressure
|
Mpa
|
14.5
|
|
19.5
|
|
37
|
Supplement
|
Tire type (FR/RR)
|
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
|
38
|
Numbers of wheels
|
pcs
|
2/2
|
2/2
|
2/2
|
4/2
|
|
39
|
lowering speed (full load)
|
mm/s
|
460
|
520
|
420
|
460
|
|
40
|
Lowering speed ( unload)
|
mm/s
|
400
|
510
|
410
|
390
|
|
41
|
Axle load distribution (full load) (FR/RR)
|
kg
|
8180/1025
|
10340/960
|
10560/1440
|
7344/816
|
|
42
|
Axle load distribution (unload) (FR/RR)
|
kg
|
2090/3115
|
2700/3540
|
3150/3850
|
3264/4896
|
