V-97
|
|
Folding size
|
218*106*72.6mm (without paddle)
|
|
Expanded size
|
242*334*72.6mm (without paddle)
|
|
Takeoff weight
|
780g(Smart battery
|
|
840g(long-range smart battery)
|
|
Maximum takeoff weight
|
Around 1190g
|
|
Wheelbase
|
372mm
|
|
Maximum ascending speed
|
5m/s
|
|
Maximum descent velocity
|
4m/s
|
|
Maximum flight speed
|
18m/s
|
|
Takeoff altitude
|
≤5000m
|
|
Maximum hovering time
|
29min
|
|
Maximum flight time
|
38/47min
|
|
Maximum driving range
|
20km
|
|
Maximum wind resistance grade
|
12m/s
|
|
Satellite positioning
|
BDS/GPS/GLONASS/GALILEO
|
|
Hovering accuracy
|
Vertical ±0.1m, horizontal ±0.3m(when visual positioning is working normally)
|
|
Vertical ±0.5m, horizontal ±0.5m(when the positioning system is working normally)
|
|
Storage
|
SD card, up to 256G supported
|
|
Working temperature
|
0℃~40℃
|
|
Wide-angle camera
|
|
Influence sensor
|
1/2-inch CMOS, 48 million pixels
|
|
Digital zoom
|
1 to 5 times
|
|
Lens
|
FOV 79°
|
|
Aperture
|
F/1.6
|
|
Camera focal length
|
4.71mm
|
|
Equivalent focal length
|
24mm
|
|
Depth of field
|
From 1 meter to infinity
|
|
ISO range
|
Video 100-26,500, photo 100-6,400
|
|
Shutter speed
|
From 1/8000 second to 2 seconds
|
|
Video resolution
|
3840*2160@30fps/@25fps/@24fps
|
|
2720*1528@60fps/@50fps/@30fps/@25fps/@24fps
|
|
1920*1080@60fps/@50fps/@30fps/@25fps/@24fps
|
|
Video format
|
MP4
|
|
Maximum bitrate of the video
|
100Mbps
|
|
Effective pixels of the image
|
48 million
|
|
Maximum size of the picture
|
8064*6048
|
|
Photo mode
|
Single photo (8 million pixels /12 million pixels /48 million pixels)
|
|
Single photo (8 million pixels /12 million pixels /48 million pixels)
|
|
Picture format
|
JPEG
|
|
File system
|
FAT32/EXFAT
|
|
AI function
|
Equipped with front-end recognition/back-end recognition/visual tracking functions
|
|
Telephoto camera
|
|
Image sensor
|
1/2.5 inch CMOS
|
|
Lens
|
FOV 21.5°
|
|
Aperture
|
F/3.0
|
|
Equivalent focal length
|
120mm
|
|
Camera Focal Length
|
14.46mm
|
|
Depth of field
|
From 10 meter to infinity
|
|
Digital zoom
|
5~30 times
|
|
ISO range
|
Video 100 to 6400, photo 100 to 6400
|
|
Shutter speed
|
From 1/8000 second to 2 seconds
|
|
Maximum resolution of video
|
3840*2160@30fps
|
|
Maximum bitrate of the video
|
100Mbps
|
|
Video format
|
MP4
|
|
Effective pixels
|
13 million
|
|
Maximum image size
|
4000 * 3000
|
|
Picture format
|
JPEG
|
|
Single photo mode
|
8 million pixels /12 million pixels
|
|
Time-lapse photography mode
|
8 million pixels /12 million pixels (1/2/5/10/30/60 seconds)
|
|
File system
|
FAT32/EXFAT
|
|
Infrared thermal imaging sensor
|
|
Types of thermal imaging sensors
|
Vanadium oxide uncooled infrared focal plane detector
|
|
Pixel spacing
|
12μm
|
|
Frame rate
|
30Hz
|
|
Video resolution
|
640*480@30fps
|
|
Image size
|
640*480
|
|
Focal length
|
19mm
|
|
Equivalent focal length
|
80mm
|
|
DFOV
|
30.7°
|
|
Aperture
|
F1.1
|
|
Focusing distance
|
From 7.6 meter to infinity
|
|
Palette
|
White heat/Black heat/Jungle/iron red/Rainbow/Aurora
|
|
Glimmer/Golden Glow/Red Heat/Medical/Golden Red
|
|
Picture format
|
JPEG(8 bits), RJPEG (16 bits)
|
|
Video bitrate
|
6Mbps
|
|
Video format
|
MP4
|
|
Photo mode
|
Single shot, timed shot (JPG 2/3/5/7/10/15/20/30/60 seconds)
|
|
Infrared wave length
|
8μm~14μm
|
|
Remote control
|
|
Size
|
204*91*47mm
|
|
Weight
|
Around 373g
|
|
Minimum delay
|
Around 120ms
|
|
Longest battery life
|
8 hours (without charging mobile device)
|
|
4 hours (when charging mobile device)
|
|
Battery type
|
Li-ion
|
|
Battery capacity
|
3900mAh
|
|
Nominal voltage
|
3.7V
|
|
Input
|
5V=2A
|
|
Working temperature
|
0℃~40℃
|
|
Charging temperature
|
5℃~40℃
|
|
Supported types of mobile device interfaces
|
Lightning、USB-c、Micro-USB
|
|
Control distance
|
20km (without interference or obstruction)
|
|
Holder
|
|
Stable system
|
Three-axis mechanical pan-tilt
|
|
Scope of structural design
|
-115° to 40° (pitch)
|
|
-30° to 30° (rolling)
|
|
-40° to 40° (yaw)
|
|
Controllable rotation range
|
10° to 90° (pitch)
|
|
Range of angular momentum
|
±0.01°
|
|
Downward vision positioning
|
|
Single-eye flow
|
TOF ranging, with an accurate ranging range of 0.3 to 6 meters
|
|
Down view light
|
Dual LED
|
|
Long-lasting smart battery
|
|
Capacity
|
5000mAh
|
|
Weight
|
Around 333g
|
|
Nominal voltage
|
14.4V
|
|
Charging limiting voltage
|
16.8V
|
|
Battery type
|
Li-ion 4s
|
|
Energy
|
72wh
|
|
Charging ambient temperature
|
0℃~40℃
|
|
The above parameters are for reference only. The detailed product parameters are subject to the actual delivery.
|
