High-Capacity Autonomous Crop Spraying and Seeding Agriculture Drone

This agriculture drone combines precise spraying with a powerful load capacity. Equipped with dual water pumps and four centrifugal nozzles, it can achieve high-flow uniform spraying and support both liquid and solid operations. Equipped with a GNSS positioning system, FPV cameras and multiple obstacle avoidance radars, it ensures precise and safe flight. Powered by high-energy lithium batteries, it supports quick replacement and has an operation efficiency as high as 35hm²/h. It is suitable for tasks such as plant protection and fertilization in large-scale farmlands, facilitating the intelligent upgrade of modern agriculture.







Product features



Large-load design, with a wide range of operations

Double water pumps and four nozzles ensure even spraying

Multi-radar obstacle avoidance ensures safer flight

Smart battery is quick to remove and has a long battery life



Technical parameters



HN-100

Expanded size

3350*3350*900mm(blade closure)

4605*4605*900mm(blade unfolded)

Folding size

1010*870*2320mm

Weight

104kg(including battery), 74kg(excluding battery)

Maximum takeoff weight

254kg

Maximum flight speed

15m/s

Hover duration

Fully loaded for 8 minutes and unloaded for 20 minutes

Battery

18s 30000mAh *2

Charging ambient temperature

-40℃~65℃

Work efficiency

35h/h

Protection grade

IP67

Spraying system

Water tank capacity

100L

Nozzle type

Centrifugal nozzle

Number of nozzles

4

Nozzle spray width

8~15m

Atomization size

30~500μm

Number of water pumps

2

Pump flow velocity

≤24L/min

Seeding system

Capacity

100kg

Applicable particle size

1~10mm

Waterproof grade

IP67

Obstacle avoidance system

Front and rear obstacle avoidance radars

2pcs

Relative height for safe obstacle avoidance ≥2 meters

Relative speed for safe obstacle avoidance ≥8m/s

Anti-landmine radar

1pc

Maximum slope (flight speed ≤2m/s),45°

HD FPV Camera

Resolution

1920*1080P

Night navigation

High-brightness night flight light

Remote control

Size

194.3*142*94.9mm

Weight

2kg

Duration

4~8h

Control distance

5~20km

The above parameters are for reference only. The detailed product parameters are subject to the actual delivery
