Performance Parameter

Light Source

Red LED ,660nm

Decode Capability

EAN-8，EAN-13，UPC-A，UPC-E，Code 39，Code 93，Code 128，EAN128，Codaber，Industoal 2 of 5，Interleave 2 of 5，Matrix 2 of 5，MSI,etc.

Scanning Type

Linear CCD

Scan Rate

270 scans per second

Trigger Mode

Manual /continuous scan

Roll/Pitch/Yaw Angle

30° /65°/55°

Resolution

0.10mm

Depth of scanning field

390mm

Print Contrast

30%,minimum reflective

Error Rate

1/5million

Indicator

LED,buzzer

Interface Support

USB-HID,RS232

Physical Parameter

Dimension

L175mm*W71mm*H101mm

Weight

249g

Housing Materials

ABS+PC

Cable Parameter

microUSB 0.7M

Electrical Parameter

Voltage

DC 5V

Current

80mA(Operating mode),30mA(Quiescent current)

Environmental Parameter

Operating Temperature

-20℃~50℃

Storage Temperature

-40℃~70℃

Humility

5%~95%（non-condensing ）

IP Level

IP54

LUX

3000-8000Lux

Impact Resistance

withstands multiple 3m drops to concrete
