Factory Sale SMB Plug Female Right Angle to BNC Female Connector TV Cable Assembly with RG316 Coaxial Cable

SMB Cable assembly Features:

  • Can be combined with BNC, MMCX, N, SMA, SMB or UHF connector;
  • Body Can be bulkhead or standard mount connectors;
  • Body Can be right angle or straight connectors;
  • Cable Can use flexible, formable or semirigid cable.



Factory Sale SMB Plug Female Right Angle to BNC Female Connector TV Cable Assembly with RG316 Coaxial Cable



The SMB cable assembly can use corrugated, flexible, formable or semirigid coaxial cable such as LMR100, LMR195, RG141, RG142, RG174, RG178, RG179, RG180, RG188, RG196, RG223, RG316, RG400, RG405, RG58 or RG59 cable; the body of SMB to BNC cable assembly is right angle or straight connectors which is plug to pin or jack to pin gender. This SMB plug to BNC female cable assembly uses a 50ohm right angle SMB for connector 1 and a 50ohm straight BNC for connector 2, Cable is 50ohm flexible cable type RG316.



Specifications

ELECTRICAL DATA
Connector 1 Series SMB
Connector 1 Style RA Plug
Cable Type RG316
Connector 2 Series BNC
Connector 2 Style Str Female
Contact Termination Solder
Shield Termination Crimp
Impedance (Ohms) 50
Low PIM No
Max Frequency 4GHz
Working Temperature -65°C  to +165°C
MATERIAL DATA
Body Material Brass
Body Finish Nickel/Ternary alloy
Contact Material Phosphor Bronze/Beryllium Copper
Contact Finish Gold/Silver
Insulator Material PTFE



Applications

  • Antennas
  • Base Stations
  • Radio Boards
  • Global Positioning System (GPS)
  • Instrumentation
  • PC/LAN
