Finisar FTLC9141RENM 100GBASE-SR4 100m CFP4 Optical Transceiver

Description:

Form Factor: CFP4
Finisar's FTLC9141RENM 100G CFP4 transceiver modules are designed for use in 100 Gigabit Ethernet links over multimode fiber. They are compliant with the CFP4 MSA and IEEE 802.3bm 100GBASE-SR4 and CAUI-4. Digital diagnostics functions are available via the MDIO interface, as specified by the CFP MSA and Finisar Application Note AN-20xx.

Warranty1 Year
ConditionNew
Temperature0-70
Data Rate100G
Distance100m
Wavelength850nm
ConnectorMPO (MTP12)

Facebook Twitter Pinterest LinkedIn 分享

Description

Description:

Hot-pluggable CFP4 form factor
Supports 103.1Gb/s aggregate bit rate
Power dissipation <4W
RoHS compliant
Single 3.3V power supply
Maximum link length of 100m on OM4 Multimode Fiber (MMF)
4x25Gb/s 850mm VCSEL-based transmitter
4x25G electrical interface
Single MPO12 receptacle
MDIO management interface
Commercial case temperature range: 0°C to 70°C

Feature:

Distance:100 m
Data Rate (max):103.1 Gb/s
Protocol:100G Ethernet Compliant
Low End Case Temperature (°C):0
High End Case Temperature (°C):70
Diagnostics:Digital
Transmitter:4x VCSEL Array
Receiver:PIN
Voltage Supply:3.3
Connector:MPO (MTP12)
Wavelength:850nm Band
