This 10,000kg Short Fixed Jib is designed for larger forklifts and is the largest capacity jib in our range.
- Maximum extension is 2 metres, with the overall jib length when retracted of 1.39 metres.
- Fitted with wide pocket centres. Zinc plated finish.
Specifications
· Safe Working Load (SWL) 10,000kg Max.
· Unit Weight 400kg
· Load Centre 930mm
· Pocket Size 230 x 110
· Pocket Centres 875 mm
· Horizontal C of G 740mm
· Vertical C of G 100mm
