Truck Description:
Concrete mixer truck is a special truck used to transport concrete for construction: due to its shape it is often called a snail car or an olive car. This type of truck is equipped with a cylindrical mixer drum to carry the mixed concrete. The mixer drum will always be rotated during transport to ensure that the concrete carried does not freeze.
Advantages:
1. FOTON chassis, quality assurance.
2. Optional from 4CBM to 18CBM
3. Engine emission standard can choose EuroⅡ,EuroⅢ,EuroⅣ,EuroⅤ.
4. Mixing drum and blade using high strength steel T510
|
Foton Concrete Mixer Truck 4 cubic meter
|
|
Truck
description
|
GVW (kg)
|
15800
|
|
Kerb weight (kg)
|
6800
|
|
Overall
dimension (mm)
|
Length
|
7025
|
|
Width
|
2320
|
|
Height
|
3700
|
|
Chassis
|
Number of axles
|
2
|
|
Allowable Passengers in cab
|
2
|
|
Air conditioner
|
For option
|
|
Wheel base(mm)
|
3400
|
|
Type of fuel
|
Diesel
|
|
Exhaust/output
|
3922ml/96kw
|
|
Tire specification
|
for option
|
|
Tank
description
|
Material
|
T510 alloy steel
|
|
Thickness
|
tank (mm)
|
5
|
|
head(mm)
|
6
|
|
Blade（mm）
|
4
|
|
Equipment
|
China pump and motor, reducer.
|
|
Mixer volume
|
4m³
|
|
Other remark
|
Above specification is just for reference, please send us your request details.
|
|
