Full color video PH4mm lightweight led billboard waterproof

Front & Rear Maintenance

Super Brightness by SMD 10000nits


  • Warranty TimeGuarantee Period 5 Years
  • CertificationUL CE ROHS FCC EMC ISO TUV ETL SGS SAA BIS SASO UV PVOC KC BQB FCC-ID FDA LVD MON C-TICK
  • Packaging DetailsWooden Box Flight Case Carton Box

Full color video PH4mm lightweight led billboard waterproof


Pioneering SMD 10000nits for Outdoor LED Screen

Better Performance in Display

High Contrast Ratio

Better Blending Effect in Color

Wider Viewing Angle

Module of hollowed-out design is made for efficient heat dissipation to stand various severe weathers in outdoors. Fully waterproof module can stand the stormy weather in outdoors



Specification:


Pixel Configuration

SMD1921

Pixel Pitchmm

4.0

Pixel Densitydot/m2

62500

Module Pixel Matrix (W×H

64×32

Module Size(mm

256(W×128(H

Module Weight(kg

0.5

Module Power Consumption Max.(W

25

Module/Panel(W×H

4×6

Panel Resolution(W×H

256×192

Panel Size(mm

1024(W×768(H×160(D

Panel Weight(kg

28

Maitainence Mode

Rear Maitainence

Panel type

Die casting Aluminum cabinet

Brightness(nits

6500

Color Temperature(K

3200—9300

Viewing AngleHor/Vert°

140/120

Power Consumption Max(W/m2

1000

Power Consumption Avg(W/m2

200-300

Operating Power Source

AC90~264Vfrequency 47-63Hz

Frame Frequency(Hz

50&60

Drice Mode

Constant Driving,1/8s

Gray Scale

65536

Refresh Rate(Hz

3840

Gray Scale per Color Level

16bit

Working Temperature/Humidity(℃/RH

-20 – 60  / 10%-85%RH

Storage Temperature/Humidity(℃/RH

-20 – 60  / 10%-85%RH


waterproof P4 led screen


P4 outdoor led display module


P4 outdoor led screen


outdoor led display cabinet 960 x 960
