Product description

The IC697CPM925 module is a CPU module for the Series 90-70 PLCs from GE Fanuc. The CPU module uses an 80486DX2 microprocessor clocked at 64 Megahertz and comes with 1 Megabyte of battery-backed memory. The shelf life of the battery is 10 years at 68 degrees Fahrenheit and the memory retention is 6 months without applied power. The IC697CPM925 module is a 32-bit floating point CPU.

The module requires a single slot in the PLC backplane. The number of total discrete I/O supported is 12 K and up to 8 K analog I/O. The power requirements of the IC697CPM925 module is 3.3 Amps nominal current at 5 Volts DC. The operating temperature range is 0 to 60 degrees Celsius with 70 cubic feet per minute of forced air-cooling. Without forced air-cooling, the operating temperature range is 0 to 40 degrees Celsius.

The accuracy of the IC697CPM925 module’s time of day clock is 3.5 seconds per day. The internal timing accuracy is .01%. The IC697CPM925 module includes a RS-422 and RS-485 compatible serial port which can be used to connect to a programmer. A lithium battery with the catalog number IC697ACC701 is installed on the IC697CPM925 module and it maintains the data and program memory when the power is removed. The old battery must be removed prior to the installation of the new battery.

To remove the IC697CPM925 module from a rack, the module must be held firmly, and the rack clips on the back cover should be squeezed to disengage the clip from the rack rail and then the IC697CPM925 module should be pulled to remove it from the backplane connector. Finally, the module should be slid along the card guide to remove it from the rack.
