GE IS230JPDMG1B IS200JPDMG1ADC DC power distribution module

Parameter

IS230JPDMG1B (VIe)

IS200JPDMG1ADC (VI)

Series

Speedtronic Mark VIe

Speedtronic Mark VI

Function

28 V DC power-distribution & diagnostic feedback

28 V DC power-distribution with fuse status

Input rating

35 A max (via JPDS companion)

35 A max direct

Connectors

11-pos. IONet + 4-pos. power

13-pos. Mate-N-Lok

Mounting

DIN-rail (hot-swap)

Panel / back-plane screws

Diagnostics

Remote, real-time (ToolboxST)

Local dry-contact only

Condition

Brand-new, factory-sealed

Warranty

12 months

GE Part Number

Series

Brief Function

Input Rating

IS230JPDMG1B

Mark VIe

28 V DC dist. + IONet remote diagnostics

35 A (bus)

IS200JPDMG1ADC

Mark VI

28 V DC dist. + fuse alarm dry-contact

35 A direct

IS230JPDSG1A

Mark VIe

28 V DC power-spread expansion board

70 A

IS230JPDSG1B

Mark VIe

Redundant power dist., dual input

70 A

IS200JPDSG1A

Mark VI

28 V DC dist., JPDB compatible

35 A

IS200JPDBG1A

Mark VI

115 V AC distribution mother board

25 A / 115 Vac

IS215JPDBA2A

Mark VI

AC expansion, 3 independent fuses

25 A / 115 Vac

IS200JPDHG1A

Mark VI

High-voltage 125 V DC dist. board

30 A / 125 Vdc

IS230JPDHG1A

Mark VIe

125 V DC dist. + diagnostics

30 A

IS200PPDAH1A

Mark VI

Power-diagnostics daughter card (plug-in)

28 V sense
