One-line essence
IC693ALG223 is a GE Fanuc 90-30 series high-density analog current input module: 16 single-ended or 8 differential channels, 0–20 mA / 4–20 mA, 12-bit plus sign resolution, direct CPU transfer without remote I/O overhead.
Straight-to-spec table
|
Attribute
|
Factory value
|
Field meaning
|
|
Channels
|
16 SE / 8 diff software selectable
|
One card covers two loops per pump
|
|
Range
|
0–20 mA, 4–20 mA, over-range to 24 mA
|
Works with old 10 V shunt resistor
|
|
Resolution
|
12 bit + sign (0.1 % LSB)
|
< 0.15 % error at 12 mA
|
|
Update speed
|
8 ms all channels
|
Fast enough for 50 Hz cascade PID
|
|
Input impedance
|
250 Ω ±0.1 %
|
Standard HART-compatible burden
|
|
Isolation
|
500 V channel-to-bus
|
Mix 24 Vdc & 110 Vac safely
|
|
Power
|
90 mA @ 5 Vdc back-plane
|
No external 24 V feed required
|
|
Connector
|
20-pin terminal block (IC693ACC337)
|
Screw-clamp, removable
|
Configuration cheat-sheet
|
Step
|
RX3i CPU
|
90-30 CPU
|
|
1
|
Slot 3, 4, 5 auto-scan
|
Slot any I/O rack
|
|
2
|
%AI0001–%AI0016 default
|
%AI001–%AI016
|
|
3
|
Range select bit %M0167 = 0 (4–20 mA)
|
DIP SW1 = OFF
|
|
4
|
Scale 0–32767 → 0–20 mA
|
Ladder SCL 32767 = 20000 µA
|
Typical loop pairings
|
Sensor
|
Cable
|
Result
|
|
Rosemount 3051 4–20 mA
|
Belden 9501 shield
|
0.1 % loop accuracy
|
|
Torque motor 0–20 mA
|
2-wire armored
|
Direct drive valve position
|
|
Retrofit 0–10 V
|
500 Ω 0.1 % 0.25 W
|
Voltage converted without new module
|
Certifications & stamps
CE, UL 508, cULus Class I Div 2 Groups A-D, ABS marine, RoHS.
15-second RFQ
Sales Manager May
ab@mooreplc.com | +86-18106909650 (WhatsApp) | WeChat: dcsfcs
Bottom line
When your 90-30 rack needs more 4–20 mA eyes without remote sub-racks, slide in IC693ALG223: no external power, no scaling headaches, just raw milliamps straight to the CPU.
