The HN-50 plant protection drone is equipped with 56 inch high-strength propeller blades, providing strong power. It has a large flow impeller pump and a water-cooled centrifugal nozzle, which can quickly switch between sowing and spraying modes. The nozzle and impeller pump that can simultaneously regulate the atomization particle size have high flow rate and efficiency. The flight control system has been completely upgraded, and the human-machine interaction is smooth and effortless. Equipped with precision ultrasonic flow meters, sensors and liquid separation detection, accurate and stable. Adopting an integrated material box, quick replacement and automatic recognition by the system. The spreader discharges smoothly, the metal disc is sturdy and wear-resistant, and the discharge is uniform. Excellent internal structure, resistant to falls and easy to maintain.
Newly upgraded with a large flow impeller pump and water-cooled centrifugal nozzle, the spray can be quickly switched;
The brand new 2.0 flight control system provides smoother human-machine interaction and makes plant protection operations easier. Integrated spraying and broadcasting, fast switching, meeting the needs of multi scene operations;
Adjustable atomization spraying, precise and efficient; A brand new operating interface, simple and beautiful, convenient interactive logic, one click access to commonly used settings, and real-time viewing of homework data. Multi language custom switching, simple operation, easy to complete homework instructions.
A series of spraying systems, equipped with water-cooled centrifugal nozzles that can adjust the atomization particle size and high flow impeller pumps, provide abundant flow and efficient operation. Equipped with precision ultrasonic flow meter, sensor and liquid separation detection, stable performance, precise spraying. Comprehensive detail optimization, sturdy and durable, more reliable.
Perception system: forward and backward obstacle avoidance, simulated ground flight.
1、Truss structure
1. Double the body strength
2. Easy folding transition
3. Durable and sturdy
2、Spray system
1. Fine atomization spray can regulate the particle size of atomization
2. Accurate and efficient
3、Broadcasting system
1. 360 ° uniform discharge
2. Umbrella shaped metal stirrer
3. Smooth sowing
4、Flight Control System 2.0
1. New operating system hardware protection upgrade
2. Stable performance
Technical parameter advantages:
1. Empty weight (excluding battery): 36.7kg
2. Empty weight (including battery): 51.4kg
3. Spread empty weight (excluding battery): 37.2kg
4. Weight of broadcasting empty machine (including battery): 51 9kg
5. Maximum takeoff weight: 101.4kg
(Note: The weight parameter may fluctuate by+1kg depending on the actual product selection and process errors)
6. Wheelbase: 2299mm
7. Unfold size:
Spray: 3045 * 3078 * 830mm
Spread: 3045 * 3078 * 890mm
8. Folding size:
Spray: 1113 * 781 * 841mm
Spread: 1113 * 781 * 890mm
9. Idle hover time: 17.5min (18S 30000mah battery)
10. Full load hover time: 7min (18S 30000mah battery)
11. Working environment temperature: 0-40 ℃
