Product features
Long endurance, suitable for complex environments
Quick disassembly without tools
All-carbon fiber material, lightweight and strong
Low-cost sustainable deployment
Technical indicators
|
ZP-10 Technical parameters
|
|
Length
|
1057mm
|
|
Width
|
1087mm
|
|
Height
|
500mm
|
|
Wheelbase between front and rear
|
830mm
|
|
Left and right wheelbase
|
980mm
|
|
Material of the body
|
Carbon fiber
|
|
Load capacity
|
10kg
|
|
Maximum takeoff weight
|
20kg
|
|
Maximum ascending speed
|
3m/s
|
|
Safe level flight speed
|
≤15m/s
|
|
Cruising speed
|
15m/s
|
|
Battery life
|
Fully loaded for 30 minutes and unloaded for 120 minutes
|
|
60 minutes @ load 5kg,100 minutes @ load 1.5kg
|
|
Practical ceiling
|
5500m
|
|
Working temperature
|
-20℃~55℃
|
|
Protection grade
|
IPX5
|
|
The above parameters are for reference only. The detailed product parameters are subject to the actual delivery.
|
