Product features
This unmanned aerial vehicle is designed to be portable and can be deployed and launched in a short time, to greatly enhance the emergency response capability.
It has excellent battery life, and can perform tasks for a long time. It also has the ability to cruise over long distances, to meet the demands of long-term and long-distance operations.
The design of the electric engine makes the noise extremely low. The radar reflection area is small and difficult to detect, to provide good concealment and suitable for covert operations.
This unmanned aerial vehicle (UAV) is cost-effective, consumable, and suitable for large-scale deployment. It reduces the economic burden of long-term operation, and is suitable for large-scale use.
Technical indicators
|
XF-S07 Technical parameters
|
|
Length
|
1920mm
|
|
Height
|
178.5mm
|
|
Wingspan
|
2240mm
|
|
Material
|
Aviation carbon fiber composite materials
|
|
Load
|
7kg
|
|
Maximum takeoff weight
|
31kg
|
|
Safe level flight speed
|
28~44m/s
|
|
Cruising speed
|
34m/s
|
|
Dive velocity
|
≥50m/s
|
|
Battery life
|
Full load 130min
|
|
Maximum range
|
270km
|
|
Practical ceiling
|
5000m
|
|
Working temperature
|
-20℃~55℃
|
|
Wind resistance grade
|
Takeoff and landing level 5, flight level 6
|
|
Protection grade
|
IPX5
|
|
Takeoff mode
|
Pneumatic ejection
|
|
The above parameters are for reference only. The detailed product parameters are subject to the actual delivery.
|
