Heavy-Lift Extreme-Altitude Industrial Cargo Drone

       The YS-05 transport drone adopts high-strength composite carbon fiber combined with aviation aluminum materials, and successfully achieving a breakthrough of reducing weight without compromising quality. It features an innovative large-sized carbon fiber propeller equipped with a multi-axis and multi-rotor coaxial system, enabling a safe return even if some blades fail. The standard battery can support full-load flight, and intelligent battery further enhances the endurance. Fast charging technology can be put back into operation in a short time. Under extreme conditions, it can perform operations in high-altitude areas. When folded, it is compact in size and can be transferred and deployed by ordinary freight vehicles. It can be applied in special scenarios such as power repair, geological exploration, and high-altitude material transportation, completely solving the last-mile transportation problem.



Product parameters



YS-05

Expanded size

4060*4060*1280mm

Folding size

2150*2150*1650mm

Model

8-axis 16-rotor

Fuselage weight

≤230kg (Smart battery 1

≤249kg (Smart Battery 2)

Maximum takeoff weight

≥530kg (Smart Battery 1)

≥549kg (Smart Battery 2)

Maximum net tensile force (sea level)

≥300kg

Maximum safe load capacity

210kg

Battery weight



≤94Kg/1set

≤114Kg/1set

Battery capacity

15° Smart battery 1

28° Smart Battery 2

Charging ambient temperature

40℃

Idle hovering duration

≥40min

≥60min

Rated battery endurance

≥11min

≥18min

Wind resistance grade

≥Level 6

Maximum horizontal speed

≥25m/s

Maximum lifting speed

±8m/S

Maximum working altitude

≥6000m

Working voltage

68V~100.8V

Working temperature

-20℃~55℃

The above parameters are for reference only. The detailed product parameters are subject to the actual delivery.
