High Power Transformer Soft Magnetic Nanocrystalline Cut C Core

What Is a Nanocrystalline Cut C Core?

A nanocrystalline cut C core is a magnetic component made from an iron-based nanocrystalline alloy with a nanocrystalline microstructure. This structure imparts superior magnetic properties, including high permeability and low core losses, making them ideal for high-frequency and high-power applications. The C-shaped design allows for easy assembly and disassembly, facilitating maintenance and customization.

Material Characteristics

Key Features

• High Initial Permeability (μᵢ > 60,000): Provides efficient magnetic flux conduction, enabling compact transformer designs without compromising performance.

• High Saturation Flux Density (Bₛ ≈ 1.20 T): Enables the core to handle higher currents without reaching saturation, ensuring reliable operation in demanding applications.

• Low Core Loss: Demonstrates minimal energy loss at high frequencies, contributing to improved efficiency and reduced heat generation.

• Wide Operating Temperature Range (–40°C to +140°C): Maintains stable performance across a broad temperature spectrum, making it suitable for various environmental conditions.

• Excellent Frequency Characteristics: Maintains stable permeability over a wide frequency range, ensuring effective noise suppression and consistent performance.

• Easy Assembly and Disassembly: The C-core design allows for straightforward assembly and disassembly, facilitating maintenance and customization.

Typical Applications

• High-Frequency Transformers: Used in power supplies and converters to step up or step down voltage efficiently.

• Solar Inverters: Employed in photovoltaic systems to convert DC to AC power.

• UPS Systems: Integrated into uninterruptible power supplies to provide backup power during outages.

• Welding Equipment: Utilized in welding machines to supply the necessary power for welding processes.

• Induction Heating Power Supplies: Applied in induction heating systems for metal hardening and other industrial processes.

Custom Options

Customized sizes, inductance values, and coating types are available. Contact us for technical consultation and design support.

Why Choose Dongguan JH Amorphous Nanocrystalline Cores

• Precision manufacturing with consistent quality

• Space-saving design optimized for modern electronic systems

• Rapid prototyping and flexible production scalability

• Full compliance with RoHS/REACH environmental regulations

Certificates

Dongguan JH Amorphous, a leading professional one-stop amorphous cores manufacturer.

We offer magnet solutions from design to worry-free after-sales. Let talk about your distinct project now!
