High Quality Bistable Solenoid Keep Holding Magnetic Solenoid

The XH3530 permanent electromagnet, epoxy resin filling,with force power on and without force power off. Support small batch orders.



Product Description

Brand Landa Model XH3530
Rated Voltage (V) DC12/24 Rated Power(W) 11W
Work Model Holding Type Holding Force (N) 150
Stroke(mm) 0 Reset Time(s) 0.2
Service Life 500 Thousand Times Certification CE,ROHS,ISO9001
Material Iron Lead Wire Length(mm) 200
Install Style screw Tolerance of Dimension gb/t1804-m
Water-proof IP65 Insulation Class B
Hi-Pot Test AC 600V 50/60Hz 2s Non-excitation Holding Force 150N
Residual Magnefism / Duty Cycle 100%
Working Temperature -10°C-100°C Thread Size(mm) M4
Thread Depth(mm) 5 Payment Term TT,PAYPAL
Sample Order Yes Warranty 1 Year
MOQ 10 pcs Supply Ability 5000 pcs per Week
Delivery Time 8 Days Port of Loading Zhongshan

Weight Packaging Details Shipment Details
N.W.(KG) G.W.(KG) Product Size(mm) Carton Box Size(mm) 20GP 40GP 40HQ
0.19 0.2 35*30 350*310*180 / / /


Product Features

• High Quality Bistable Solenoid Keep Holding Magnetic Solenoid

• Small in size

• Big in force

• With force power on and without force power off

• Easy to operate

• Epoxy filled

• IP65

• Wide range of application

• 10 years of designning and producing experience

• OEM/ODM is welcomed


Product Details

Keep Holding Magnetic Solenoid


IP65 Waterproof Permanent Electromagnet


High Quality Bistable Solenoid


Holding electromagnet DC 24V


Permanent Electromagnet XH3530
