Field Note: HIMA Z7127 8-Channel Analog Input Module (HIMatrix Z Series)
Quick Specs – Straight from the Manual
• 8 universal inputs – current (±20 mA), voltage (0–10 V), or resistance
• 16-bit resolution, 0.1 % FS accuracy
• 500 Hz sampling, 5 ms update per channel
• 24 V DC supply, < 10 mA per channel
• -40 °C … +85 °C, IP65 front
• CCNET protocol to HIMatrix CPU
• MTBF > 1 million hours
FAQ -One-Liner Answers
Q: RTD & 4-20 mA on the same card?
A: Yes -each channel software-selectable.
Q: Need external excitation?
A: No -24 V loop supply built-in.
Q: Hot-swap?
A: Yes -DIN-rail clip, 30 s swap.
Q: Redundancy?
A: Pairs with F8650X dual-CPU for SIL-3.
Ready-to-Ship HIMA Kit
|
Part Number
|
Description
|
|
Z7127
|
8-ch analog input – this unit
|
|
Z7126
|
4-ch analog input
|
|
Z7128
|
8-ch RTD/TC only
|
|
F8650X
|
Dual-CPU safety controller
|
|
F7130A
|
24 V DC 10 A supply
|
|
F7133
|
Power distribution module
|
|
F7553
|
CCNET coupling module
|
|
F4111A
|
16-ch digital input
|
|
F4204
|
8-ch relay output
|
|
F8641
|
8-ch analog output
|
|
Z6011
|
2 m CCNET cable
|
|
Z6013
|
5 m CCNET cable
|
|
Z6018
|
10 m CCNET cable
|
Call PLC Autocontroller – same-day ship, no MOQ.
