Huawei SSN1EMS4 03051252 optix OSN1500B Board

Product Description

Huawei SSN1EMS4 Board Product Overview

Huawei SSN1EMS4 Board is an Ethernet switching processing board, which is mainly used to solve telecommunication application fields such as Ethernet service access, bandwidth management, and Ethernet service layer 2 switchings. A typical networking application of the Ethernet switch processing board is shown in Figure 1. It can implement Ethernet access and aggregation,

Layer 2 switching of Ethernet data, port isolation, flow classification, data flow control, VLAN management, and priority. Configuration and other data features, as well as functions such as data encapsulation/decapsulation, virtual concatenation, and SDH mapping / demapping.  At the same time, it can be connected with broadband access equipment and data communication equipment to provide a network-wide solution.

Huawei SSN1EMS4 Board Product Feature

Supports PORT-based transparent transmission.

Support EVPL services that share PORTs.

Support EVPL services that share VCTRUNK.

Supports up to 8000 LINK services.

Supports up to 512 blacklists and 512 static MAC addresses. The blacklist only supports destination MAC address verification, and does not support source MAC address verification.

Support source MAC address self-learning function, the size of MAC address table is 128K, support setting and querying of MAC address aging time.

Support static MAC routing configuration.

Support query of dynamic MAC address.

The maximum number of VBs supported is two, and the maximum number of each VB logical port is 40.

Supports EPLAN services based on the IEEE 802.1d MAC bridge.

Supports data isolation based on VB (Virtual Bridge) + VLAN.

Supports up to 4,000 VLAN services.

Supports EVPLAN services based on IEEE 802.1q Virtual Bridge and IEEE 802.1ad Provider Bridge.

Our Advantages

We have Huawei SSN1EMS4 for sale, including refurbished and new ones, and the price is usually 90% lower than the original supplier's price. Our super fast turnaround time and high-quality inventory all over the world mean that we can accurately deliver the products replaced on the same day to the place where they are needed, and minimize network downtime.

Huawei SSN1EMS4, like all our hardware, takes comprehensive warranty as the standard. Whether you need new products or renovated products, we only purchase green market equipment of the highest quality and environmental protection. All these are provided at the best possible price, and a large amount of cost-effectiveness will be directly passed on to you.

Huawei SSN1EMS4 represents only one product in our world-class hardware portfolio. The portfolio includes very well-known industry names, such as Nokia, Huawei, ZTE, Siemens, Nortel, Ericsson, Alcatel, Lucent, etc. We have a lot of inventory, thank you very much for sharing with customers.
