Hyundai R235lcr9 bearings-main XKAQ-00986

XKAQ-00986 bearings are used in the final drive Bearing system of HYUNDAI heavy machinery equipment:

XKAQ-00986 HYUNDAI BEARING parts

Apply to R110-7, R110-7A, R140LC9, R140LC9A, R140LC9S, R160LC9, R160LC9A, R160LC9S, R180LC9, R180LC9A, R180LC9S, R210LC7A, R210LC9, R210LC9BC, R210LC9BH, R210NLC9, R220LC9A, R220NLC9A, R235LCR9







Hyundai excavator final drive bearing XKAQ-00986

P/N

XKAQ-00986

Material:
GCR15
i/d mm
O/D
mm
H mm
Brand: ZHZB
Precision
P0 , P6 , P5
Structure:
Angular contact bearing

Product features:
1. Special bearing for excavator travel gearbox
2. It can bear the load from both axial and radial at the same time
3. High-strength high-quality steel
4. Smooth rotation and low noise
5. Compared with other companies' final drive bearings, the service life is increased by 50%
Our advantage:

100% factory quality inspection;
Minimum order quantity: 1;
Faster delivery efficiency;
Higher cost performance;
Have a mature production line so that we can customize according to the samples or drawings provided by customers;
Professional manufacturer of final drive bearings for excavators. Have many years of manufacturing experience

Production Process






Product Photos

XKAH-00986HYUNDAI XKAH-00986Bearing XKAH-00986



Any other parts for the final drive gearbox system you need , pls search from below picture and form list then mark to me , we will quote to you.

HYUNDAI PARTS



Pos.

Part No

Qty

Parts name

Comments

*.

@

[1]

TRAVEL MOTOR ASSY

SEE 4150

*.

@

[1]

TRAVEL MOTOR ASSY

SEE 4150

*.

@

[1]

TRAVEL MOTOR ASSY

SEE 4150

*-2.

31N6-40040BG

[1]

T/REDUCTION GEAR



*-2.

31N6-40041BG

[1]

T/REDUCTION GEAR



*-2.

31N6-40042

[1]

T/REDUCTION GEAR



*-2.

31N6-40043

[1]

T/REDUCTION GEAR



N1.

XKAQ-00217

[1]

HOUSING



2.

XKAQ-00218

[2]

BEARING-MAIN



2.

XKAQ-00986

[2]

BEARING-MAIN



3.

XKAQ-00219

[1]

SEAL-FLOATING



4.

XKAQ-00220

[1]

SHIM



5.

XKAQ-00221

[1]

RETAINER



6.

XKAQ-00222

[12]

BOLT-HEX



7.

XKAQ-00223

[2]

PIN-PARALLEL



N8.

XKAQ-00224

[1]

GEAR-RING



9.

XKAQ-00225

[1]

COUPLING



9.

39Q6-42170

[1]

COUPLING



10.

XKAQ-00226

[1]

CARRIER 2 ASSY



10-1.

XKAQ-00227

[1]

CARRIER 2



10-2.

XKAQ-00228

[4]

GEAR-PLANET 2



10-3.

XKAQ-00229

[8]

BEARING-NEEDLE 2



10-4.

XKAQ-00230

[8]

WASHER-THRUST



10-5.

XKAQ-00231

[4]

PIN 2



10-6.

XKAQ-00232

[4]

PIN-SPRING



10-7.

XKAQ-00208

[2]

RING-THRUST



11.

XKAQ-00233

[1]

CARRIER ASSY 1



11.

XKAQ-00653

[1]

CARRIER ASSY 1



11-1.

XKAQ-00234

[1]

CARRIER 1



11-2.

XKAQ-00235

[1]

GEAR-SUN 2



11-3.

XKAQ-00236

[1]

RING-RETAINING



11-4.

XKAQ-00237

[3]

GEAR-PLANET 1



11-5.

XKAQ-00238

[3]

BEARNG-NEEDLE 1



11-6.

XKAQ-00239

[6]

WASHER-THRUST



11-6.

XKAQ-00657

[6]

WASHER-THRUST



11-7.

XKAQ-00240

[3]

PIN 1



11-8.

XKAQ-00241

[3]

PIN-SPRING



11-9.

XKAQ-00655

[3]

PIN-SPRING



12.

XKAQ-00242

[1]

GEAR-SUN 1



12.

XKAQ-00402

[1]

GEAR-SUN 1



12.

XKAQ-00795

[1]

GEAR-SUN 1



13.

XKAQ-00243

[1]

COVER



14.

XKAQ-00214

[1]

PAD



15.

XKAQ-00244

[20]

BOLT-SOCKET



16.

XKAQ-00245

[2]

SCREW-HEX SOCKET



17.

XKAQ-00246

[3]

PLUG-HYDRAULIC



18.

XKAQ-00247

[3]

O-RING



19.

XKAQ-00248

[1]

NAME PLATE



19.

XKAQ-00991

[1]

NAME PLATE



N.

@

[AR]

NOT SUPPLIED PARTS
