Hyundai slewing bearing XKAQ-00089 XKAQ00089 for R110-7

Hyundai excavator Slewing motor bearing XKAQ-00089

XKAQ-00089 BRG.;HYUNDAI parts fit: R110-7, R110-7A, R140LC-7



Hyundai excavator Slewing bearing XKAQ-00089

P/N XKAQ-00089 Material:
GCR15
i/d mm
O/D
mm
H mm
Brand: ZHZB
Precision
P0 , P6 , P5
Structure:
Cylindrical Roller Bearings

Product features:
1. Special bearing for excavator slewing gearbox
2. With high radial load capacity, it can also bear axial load in any direction.
3. High-strength high-quality steel
4. Long service life
5. Smooth rotation, low noise

Our advantage:
100% factory quality inspection
Respond to customer questions within one day;
Allow small orders;
Faster transportation efficiency
Good after-sales service.
Professional manufacturer of bearings for slewing gearboxes of excavators. Has many years of manufacturing experience

Production Process






Product Photos

XKAQ-00089Hyundai XKAQ-00089Bearing XKAQ-00089



※Any other parts for the Slewing motor system you need , pls search from below picture and form list then mark to me , we will quote to you.

Hyundai parts

Pos.

Part No

Qty

Parts name

Comments

*.

@

[1]

  SWING MOTOR ASSY

     SEE 4090

*-2.

31N4-10140

[1]

  SWING REDUCTION GEAR



*-2.

31N4-10141

[1]

  SWING REDUCTION GEAR



*-2.

31N4-10142AR

[1]

  SWING REDUCTION GEAR



1.

XKAQ-00134

[1]

  CASING



1.

XKAQ-00332

[1]

  CASING



2.

XKAQ-00249

[1]

  SHAFT-DRIVE



3.

XKAQ-00102

[1]

  GEAR-RING



5.

XKAQ-00100

[1]

  GEAR-SUN NO.2



5.

XKAQ-00278

[1]

  GEAR-SUN NO.2



*-21.

XKAQ-00271

[1]

  CARRIER NO.1 ASSY



6.

XKAQ-00099

[3]

  GEAR-PLANET NO.1



7.

XKAQ-00098

[1]

  GEAR-SUN NO.1



7.

XKAQ-00277

[1]

  GEAR-SUN NO.1



9.

XKAQ-00096

[1]

  CARRIER NO.1



11.

XKAQ-00094

[3]

  PIN ASSY NO.1



12.

XKAQ-00093

[6]

  WASHER-THRUST(B)



13.

XKAQ-00092

[1]

  WASHER-THRUST(A)



13.

XKAQ-00057

[1]

  PLATE-SIDE 1



23.

XKAQ-00086

[3]

  PIN-SPRING



24.

XKAQ-00085

[4]

  RING-STOP



29.

XKAQ-00080

[3]

  CAGE-NEEDLE



*-22.

XKAQ-00272

[1]

  CARRIER NO.2 ASSY



4.

XKAQ-00101

[4]

  GEAR-PLANET NO.2



8.

XKAQ-00097

[1]

  CARRIER NO.2



10.

XKAQ-00095

[4]

  PIN ASSY NO.2



12.

XKAQ-00093

[4]

  WASHER-THRUST(B)



23.

XKAQ-00086

[4]

  PIN-SPRING



16.

XKAQ-00091

[2]

  PIN-KNOCK



17.

XKAQ-00090

[1]

  BEARING-SPH ROLLER



18.

XKAQ-00089

[1]

  BEARING-CYL ROLLER



19.

XKAQ-00088

[10]

  BOLT-SOCKET



20.

XKAQ-00087

[1]

  SEAL-OIL



21.

XKAQ-00049

[1]

  PLUG



22.

XKAQ-00066

[2]

  PLUG



25.

XKAQ-00084

[1]

  RING-STOP



26.

XKAQ-00083

[1]

  SPACER



27.

XKAQ-00082

[1]

  PLATE-COVER



28.

XKAQ-00081

[6]

  BOLT-HEX



31.

XKAQ-00988

[4]

  CAP-RUBBER



Company

ZHZB Mission:We are committed to providing bearing component solutions for all construction machinery and equipment!!!

ZHZB was established in 2004 and has been committed to the development and production of engineering machinery bearings. Our products are widely used in mining equipment, road machinery, metallurgy, wind power generation, excavators and other heavy equipment and have been well received by customers!





Packaging



Delivery:

1.We will send express delivery for less than 45 kg, which is more convenient door-to-door.
2.45-200 kg we will choose air transportation, the safest, fastest, and the most expensive
3.For more than 200 kg, we will send it by sea to reduce transportation costs.



Why choose us?

  ✬1.Trusted Product


  ✬2.Advanced Technology


  ✬3.Reliable Service


  ✬4.Competitive price




FAQ

Q1: I want to buy your products, how can I pay?
A: You can contact me through Whatsapp to send bank account to you.

Q2: If we don't find what we want on your website, what should we do?
A: You can email or Whatsapp us the descriptions and pictures of the products you need, we will check whether we have them. We develop new items every month. and some of them have not been uploaded to website in time. Or you can send us sample by express, we will develop this item for bulk purchasing.

Q3: Can we buy 1 pc of each item for quality testing?
A: Yes, we are glad to send lpc for quality testing if we have the item you need in stock
